    Rapid Ref : CK-212PCSF  Mfr Ref : 212PCSF

    CK 3.8m (12.5ft) Superflex Power Cable, G3/8" Machine Connection 45V03SF
    212PCSF CK-212PCSF

    £61.77  EX VAT
    SSP Suggested Selling Price = £123.54  YOU SAVE £61.77
     Buy in 3 easy interest free payments of £20.59† with

    SuperFlex.

    CK MR140 Torch Parts FAQs

    Spare parts for a water-cooled micro TIG torch: what wears, what each part does and how to match the right replacement.

    How do I identify the right replacement parts for my micro torch?icon-minus-redicon-plus-red

    Start with the torch's own markings and the maker's manual, which normally includes a parts list or diagram. If you still have the old part, note any number on it and measure the thread, the length and the electrode size it holds. Torch styles differ, so a cup, collet body or back cap that looks the same may not fit; check the style before ordering.

    Makers advise using their own listed replacement parts rather than adapting something close. If you are unsure, send our team a clear photo of the torch head and the part you want to replace and we can help you match it.

    When would I use a gas lens instead of a standard collet body?icon-minus-redicon-plus-red

    A gas lens takes the place of the standard collet body and passes the shielding gas through fine mesh, which reduces turbulence and gives smoother gas coverage. Torch makers say this can allow a longer tungsten stick-out, which helps you see the weld pool and reach into tight joints. A standard collet body is simpler and often perfectly good for everyday work with a short stick-out.

    Only the body changes. Check your manual for the collet type and the cup that your torch takes with a gas lens, and make sure both match the tungsten diameter. The fine mesh can become dirty or damaged, so inspect it whenever you change the electrode.

    Which parts of a micro torch wear out and how can I tell?icon-minus-redicon-plus-red

    Typical wear items are the tungsten, collet, collet body or gas lens, cup, O-rings, insulator and back cap. Look for a tungsten that will not stay gripped, a collet or body with damaged threads or heat marks, a cracked or chipped cup, and a seal that is flattened or missing. Too much current can overheat and distort the collet and collet body.

    Torch makers advise checking all the consumable parts before each use, cleaning them and replacing any that are damaged straight away. Wear depends on the current, the duty cycle and how carefully the torch is handled, so there is no fixed replacement interval.

    What should I check on the power cable, gas hose and water hoses?icon-minus-redicon-plus-red

    Switch off the power source, disconnect it from the mains and shut off the gas and coolant before handling the cable assembly. Then check the cable and its insulation, the gas hose, the water hoses and all connectors for cuts, kinks, heat damage or looseness, and keep the contact surfaces clean so they make good electrical contact. Check the insulation on the handle and other insulated parts too.

    Torch makers say to replace damaged parts rather than make temporary repairs. Do not use a torch with a damaged cable or connector, and have any repair to the cable assembly done by a competent person following the maker's manual.
