Spare parts for a water-cooled micro TIG torch: what wears, what each part does and how to match the right replacement.
Start with the torch's own markings and the maker's manual, which normally includes a parts list or diagram. If you still have the old part, note any number on it and measure the thread, the length and the electrode size it holds. Torch styles differ, so a cup, collet body or back cap that looks the same may not fit; check the style before ordering.Makers advise using their own listed replacement parts rather than adapting something close. If you are unsure, send our team a clear photo of the torch head and the part you want to replace and we can help you match it.
Switch off the power source, disconnect it from the mains and shut off the gas and coolant before handling the cable assembly. Then check the cable and its insulation, the gas hose, the water hoses and all connectors for cuts, kinks, heat damage or looseness, and keep the contact surfaces clean so they make good electrical contact. Check the insulation on the handle and other insulated parts too.Torch makers say to replace damaged parts rather than make temporary repairs. Do not use a torch with a damaged cable or connector, and have any repair to the cable assembly done by a competent person following the maker's manual.
Signs include drips or damp at the torch head, handle or hose joints, a falling coolant level, or a torch that overheats. The leak may start somewhere other than where the water shows, such as the cooler, a water line, the cable or the neck. Common causes are loose connections, worn seals or O-rings and a damaged hose. Low coolant flow can overheat the torch, and a liquid-cooled cable assembly can leak if it overheats.Stop welding and switch off. Touching live metal parts can give a fatal electric shock, so never carry on welding with a leak. Replace the faulty part with the correct one, use the coolant the maker specifies, and check the level and the flow before striking an arc.
Thoriated tungsten contains a small amount of radioactive thorium. The greatest hazard is the fine dust made when grinding, not the welding itself, so grinding should be done on a dedicated wheel with local dust extraction, with suitable respiratory protection worn unless only a very small number of electrodes is ground, and eye protection if the wheel has no viewing screen. Ceriated or lanthanated electrodes are generally acceptable alternatives, and using a thoriated type should be justified.HSE guidance on welding fume points to local exhaust ventilation for regular TIG welding indoors. When you buy spare tungsten, check the type marking on the pack and the safety data sheet, and consider in your risk assessment whether a thorium-free type would do the job.
