    Rapid Ref : CKM230

    Machine Series Water-Cooled CKM230 Machine Torch Package, 300 Amp 180° with Triflex Cable
    CKM230

    Select Option
    Prices From £246.70 ex VAT
     Buy in 3 easy interest free payments of £34.06† with

    Barrel Front Loading Series.

    Machine TIG Torches FAQs

    Answers to common questions about machine (mechanised) TIG torches fitted to carriages, positioners and automated welding heads.

    When should I choose a water-cooled machine TIG torch instead of a gas-cooled one?icon-minus-redicon-plus-red

    Gas-cooled torches suit lower currents. They are compact and light and need no extra cooling equipment. Water-cooled torches are generally chosen for consistently high current, long production runs, thick material and automated work, because active cooling helps the torch and its wear parts last longer and keeps weld quality steadier.

    Because a machine torch often welds for long periods without a break, many users lean towards water cooling as the current rises. Check the torch's rated current, shielding gas and duty cycle against your actual welding current and arc-on time rather than choosing on size alone.

    What does arc voltage control do on a machine TIG torch?icon-minus-redicon-plus-red

    Arc voltage rises and falls with the distance between the tungsten and the work. An arc voltage control compares the measured voltage with a preset value and drives a slide to raise or lower the torch, so the arc length stays steady along the joint.

    That helps keep penetration and heat input consistent on long welds, and it can also compensate as the tungsten erodes. It is normally an add-on unit used with a machine torch, so check that the torch body can be mounted on the slide you plan to use.

    Do I need eye protection and screens around an automated TIG station?icon-minus-redicon-plus-red

    Yes. The arc gives off ultraviolet, visible and infrared radiation whether it is started by hand or by a controller. HSE describes arc eye as an injury to the front of the eye after exposure to welding radiation, usually becoming painful and red a few hours later. UV can also cause sunburn-like reddening of skin.

    Face and eye protection with a suitable filter, covered skin, and non-reflective screens for anyone nearby are the usual controls. Anyone setting up or watching the torch while the arc is on needs the same protection as a welder. Follow your risk assessment.

    What should I check on the cable, hoses and connections of a machine torch?icon-minus-redicon-plus-red

    Check the torch, leads and connectors for damage at regular intervals. Welding safety guidance advises that welding leads, connection devices and the torch should be checked for fitness for use, with damaged or worn parts repaired or replaced, and that electric shock is the principal risk in arc welding.

    On a machine torch, also look at how the cable and hoses move with the carriage or positioner. Avoid tight bends, kinks, trapped hoses and strain on the connectors. Isolate the machine before touching connections, and use the maker's instructions to tell you what to inspect.
