Straight answers to the questions people ask most when choosing and using a welding positioner.
A welding positioner holds the workpiece and turns it, so you can weld in a comfortable, favourable position instead of moving around the work. The most common type is the rotary positioner, a powered turntable or faceplate that rotates round parts such as pipes, flanges, tanks and shafts under a stationary torch.This gives more even welds, better control of the weld pool and less operator fatigue, and it makes circumferential welds much easier. It also suits automated welding and cladding, because the work moves at a steady, repeatable speed.
Capacity is the weight of work a positioner is rated to carry, but the rating depends on how the load sits on the table. A load centred on the axis of rotation is the easy case. If the centre of gravity is offset from the centre, or the table is tilted, the positioner can safely carry less.The maker normally gives ratings for different offsets and angles, so check these against your heaviest and most awkward workpiece, and allow a good margin. Remember to include any fixtures, chucks and clamps in the weight.
For circumferential welds, the rotation speed sets the travel speed of the weld, which affects penetration, bead shape and heat input. The speed you need depends on the process, the diameter of the work, the material and the current.Positioners normally have variable speed control, so you can set a steady speed and repeat it. Many have forward and reverse, a footswitch or remote control, and some programmable models can set the speed, direction and sequence for you. Remember that a given rotation speed gives a faster surface speed on a larger diameter.
A positioner with a hole through the centre of the table lets the work pass through, or lets you feed cables, hoses and gas lines through. It is useful for long pipes and shafts that extend through the table, and for supplying a purge gas to the inside of pipework while you weld.If your work is long or you need to purge the inside of a pipe, choose a positioner with a hole large enough for what you need to pass through it.
