CK Flex-Loc 230 / 250 Torch Parts FAQs
Heads, bodies, handles, cables, hoses and seals for a water-cooled lockable-head TIG torch: how to pick the right part and look after it.
How do I work out which head or body fits my torch?

Heads and bodies are made in different size classes tied to the torch rating, so they are not interchangeable between classes unless the maker says so. Find the torch model on the handle, body or paperwork, then look it up in the maker's parts list. It shows which head goes with which heatshield and screw, and which body comes with which O-rings.
Also check the cooling type: water-cooled and gas-cooled bodies are listed as different parts, so do not assume a body that screws on is the right one. If the model is unclear, our team can help you work it out from the old part.
How do I choose a replacement power cable or water hose?

First be clear which part you need. The power cable carries the welding current and, on many torches, the returning coolant, while the water hose carries coolant to the torch. Do not swap them over when reconnecting.
Then match the details in the maker's parts list: the length, whether you want the standard or the more flexible version, and the connector style and thread at the machine end. Some fittings have left-hand threads, so a connector that looks right may not fit. Use a power cable that is correctly sized for the torch rating, as the maker warns against under-sized or badly joined cables.
Should I replace one cable or hose, or the whole set?

Makers list the power cable, water hose and gas hose separately, and also sell combined sets of two or three pieces. If only one piece is cut or leaking, replacing that piece is usually reasonable.
If a power cable has overheated, find out why before fitting a new one. Low coolant flow, a kinked or clogged hose or a faulty cooler are the usual suspects, and fitting a new cable without fixing the cause may damage it as well. Where the cable and hoses are of similar age and condition, replacing them together can save a repeat job.
How can I tell a power cable or hose needs replacing?

Inspect cables and hoses often. Cuts, exposed wire, a cover that is hard, cracked or discoloured, a melted or shrunken section, a bulging hose and any leak are all reasons to stop using it. Torch makers say cables and hosepacks must be undamaged and correctly insulated, and that damaged, under-sized or badly joined cables must not be used, because bare conductors can cause a fatal shock.
Switch off and isolate the machine before you inspect it, and do not make temporary repairs. A damaged power cable is also an electrical hazard, so it should not be left in service.
