ESAB Magnetic Inspection Mirror 500mm
0000595319

Name: ESAB Magnetic Inspection Mirror 500mm
SKU: 0000595319
Price: 17.82 GBP

£17.82 EX VAT

SSP Suggested Selling Price = £20.97 YOU SAVE £3.15

ESAB Magnetic Inspection Mirror 500mm.

Inspection Equipment FAQs

Straight answers to the questions people ask most when choosing and using weld inspection tools.

What hand tools are used for weld inspection?

Common tools include weld gauges for measuring weld size and shape, fillet gauges for checking the leg length and throat, inspection mirrors for seeing places the eye cannot reach, a good torch or lamp, a magnifier, and a ruler or tape. A thermometer is used to check preheat and interpass temperatures.

Which you need depends on the work and the standard you follow. A small basic kit covers most workshop checks.

How does a fillet weld gauge work?

A fillet gauge has a set of notched blades or profiles of different sizes. You select the blade for the stated weld size and set it against the plates to see whether the weld matches or exceeds that size. Some gauges also check the throat or the convexity of the weld.

Hold it square to the joint and check at several places along the weld. A gauge in good condition gives a quick pass or fail check against the size on the drawing.

What is a cam-type welding gauge used for?

A cam gauge is a multi-purpose tool for measuring several features of a weld, such as the leg length of a fillet, the reinforcement of a butt weld, the depth of undercut and the bevel angle. A moving cam and scale give the reading.

It is a useful all-round gauge for checking a weld against the drawing or specification. Learn its scales and technique before relying on it, and keep it clean, because a damaged gauge gives wrong readings.

Why do gauges come in metric and imperial versions?

Drawings and specifications are written in either metric or imperial units, depending on the industry, the age of the design and the country. A gauge with the right scale lets you read the size you need directly, without converting.

Some gauges have both scales on them. Choose the one that matches the drawings you work to, and check that markings are clear and not worn.

See all 6 questions for this category
