    Rapid Ref : 79014200X

    GF 4 Pipe Cutting Machine, without Feed
    79014200X

    Select Option
    Prices From £5990.00 ex VAT
    Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

    The new GF series sets new standards in orbital pipe machining. Numerous innovative functions combined with an ergonomic design create significant advantages for you in the industrial prefabrication of pipeline systems. Cutting and bevelling high-alloy steel (stainless steel), low and unalloyed steel, plastics, casting materials and non-ferrous metals in just seconds, using the “Planetary Cutting” method.

    • Anthracite-coloured coated components for improved sliding properties and protection against corrosion
    • Stainless steel clamping attachments (Code 790142241) for protection against contact corrosion included
    • Locking mechanism prevents unauthorised usage and theft
    • A new ergonomically-designed motor handle for a safe and comfortable operating position, which also enables easy cutting of elbows
    • Integrated line laser to determine the cut-off point
    • 2 position clamping jaws to reduce chatter and enable smaller lengths of pipe to be machined
    • 1 multifunctional tool for all adjustments on the machine
    • Extended speed range (65 - 215rpm), ideal for the cutting of high-performance materials (Hastelloy®, P91, etc.)
    • Swivel cable with a quick-disconnect coupler for easy and quick replacement of power cables
    • The new chip guard protects against flying chips and comes with a measuring port

    Product Details

    Machine Includes:

    • 1 Transportation Case
    • 1 Saw blade (Code 790042064)
    • 1 Set of stainless steel clamping attachments
    • 1 Mounting Plate
    • 1 Tool Set
    • 1 Tube of saw blade lubricant GF TOP
    • 1 Bottle of special gear oil
    • 1 Set of operating instructions and spare parts list
    • Quick disconnect swivel cable

    Brochures, Manuals & Videos

    Related Items

    GF Pipe Cutting Machines FAQs

    Practical answers on choosing, setting up and using orbital pipe cutting and bevelling machines that carry a small circular saw blade round the pipe.

    Which materials can this type of machine cut, and do I change the settings for each?icon-minus-redicon-plus-red

    Machines of this type are made to cut and bevel stainless and other high-alloy steels, low-alloy and plain steels, cast materials, non-ferrous metals such as aluminium, copper and brass, and many plastic pipes. Most have an electronic variable speed control so the blade speed can be matched to the material.

    In general, tougher alloys call for a slower blade speed and a blade made for that material, while softer metals and plastics need their own care to avoid clogging or melting. Do not guess: the manual and the blade maker's chart give the speed and blade for each material, and the data plate shows what your machine can handle.

    Why does the wall thickness a machine can cut depend on the material?icon-minus-redicon-plus-red

    Harder, tougher materials need more cutting force and heat the blade more, so a machine that copes with a given wall in mild steel may only manage a thinner wall in a high-alloy steel. For that reason makers usually quote the wall thickness range as depending on the material.

    Makers also note that a thicker wall can sometimes be cut by using a manual feed or by making the cut in more than one pass, depending on the blade diameter. Treat that as something to check, not assume: look up your pipe diameter, wall thickness and material against the machine's application table in the manual before you start.

    Can the clamping jaws damage or contaminate stainless steel pipe?icon-minus-redicon-plus-red

    They can if the wrong ones are used. Iron picked up from steel or cast iron tooling can be left on the surface of stainless steel, where it may rust later and make the pipe look as if it is corroding. For this reason makers supply stainless steel clamping attachments for use on stainless pipe, to protect against contact corrosion.

    Fit the stainless attachments before clamping stainless pipe, keep them clean, and do not use them on carbon steel and then on stainless without cleaning them first. Where the machine is shared between materials, a thorough clean before stainless work is good practice.

    How do I mark and line up the cut position accurately?icon-minus-redicon-plus-red

    Many machines include a line laser that projects a line across the pipe to show exactly where the blade will cut. Mark the pipe at the position you want, bring the laser line onto the mark, then clamp the pipe so it cannot slip.

    Allow for the thickness of the blade, and for any material that will be removed by a bevel, when you measure the length you need. Do not look into a laser beam, keep the lens clean, and follow the manual for fitting and aligning the laser, as the method differs between machines.
