    Rapid Ref : GK-165-074-2

    Gullco 4 Motion Welding Torch Holder with Standard Rack Box
    GK-165-074-2

    £637.00  EX VAT
     Buy in 3 easy interest free payments of £212.33† with

    For mounting on the KAT® horizontal rack arm to provide 5” (127mm) of vertical adjustment, 360° torch rotation and two directional tilt. Supplied complete with standard 1 1/8” (29mm) I.D. swivel clamp and insulated linkage for the gun holder which is suitable for most semi-automatic welding guns. Gun holder jaws are adjustable from 5/8” (16mm) to 1 1/2” (38mm).

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    Gullco KAT Accessories FAQs

    Answers on the rack boxes, arms, clamps, holders and supports that position a torch or gun on a track carriage.

    Why does the torch height and stick-out matter when I set up the accessories?icon-minus-redicon-plus-red

    The rack box and holder set the distance between the torch and the work. For MIG welding that is the contact tip to work distance, which gives the electrode stick-out. Too long a stick-out gives poor bead shape, shallow penetration and an unstable arc, and changes the current for a given wire feed speed. A typical guide is about 6 to 13 mm for short-circuit transfer and 13 to 25 mm for other transfer types.

    Set the distance from your welding procedure, lock the rack box, and re-check it once the carriage is on the track and moving, because small shifts in the plate or track change it. Follow the wire and gas maker's advice for your set-up.

    How should I route and support the torch cable?icon-minus-redicon-plus-red

    The torch cable or bundle has weight and stiffness, and it can pull the torch out of line, snag on the track or surroundings, and interrupt the weld. A cable support bracket on the carriage, where the maker offers one for your model, helps to carry that weight.

    Fit the support so the cable has enough slack for the whole length of travel, keep it clear of the drive and the hot work, and check it as the carriage moves through the full run before you strike the arc. Inspect cables regularly for breaks and abrasion, and replace any that are damaged.

    How do I look after the accessories and clamps?icon-minus-redicon-plus-red

    One carriage maker's manual says to clean dust and spatter off regularly, paying attention to the drive gear and wheel assemblies, and to lubricate occasionally, with a dry lubricant preferred and even light machine oil better than none. Apply the same habit to racks, slides and clamp threads so the adjusters stay free.

    The same manual calls for a full strip-down inspection at least once a year: clean, grease and inspect moving parts for wear, check cables for breaks and abrasion, replace damaged or worn parts and check that fastenings are tight. Look over arms, clamps and threads before each job, and replace anything that no longer locks firmly.

    What safety points apply when adjusting accessories on a carriage?icon-minus-redicon-plus-red

    Do not adjust the rack box, arm or clamps while the drive could move. Carriage makers say to keep hands away from the underside of the carriage whenever there is the slightest possibility of motion, to avoid or protect against objects protruding from moving equipment that create pinch points, and not to wear loose clothing, jewellery or loose long hair near moving parts.

    The HSE describes shear points where moving parts pass each other or a fixed object, and advises a safe stop procedure before maintenance. Stop the carriage, switch off and disconnect it, let hot parts cool, and check every clamp is tight before restarting.
