Gullco KAT Accessories FAQs
Answers on the rack boxes, arms, clamps, holders and supports that position a torch or gun on a track carriage.
Why does the torch height and stick-out matter when I set up the accessories?

The rack box and holder set the distance between the torch and the work. For MIG welding that is the contact tip to work distance, which gives the electrode stick-out. Too long a stick-out gives poor bead shape, shallow penetration and an unstable arc, and changes the current for a given wire feed speed. A typical guide is about 6 to 13 mm for short-circuit transfer and 13 to 25 mm for other transfer types.
Set the distance from your welding procedure, lock the rack box, and re-check it once the carriage is on the track and moving, because small shifts in the plate or track change it. Follow the wire and gas maker's advice for your set-up.
How do I set the torch height for machine flame cutting?

For machine cutting, the torch is held in a holder with a rack so the nozzle height can be set and locked, then stays constant as the carriage travels. The nozzle-to-plate distance matters: too high or too low disturbs the oxygen flow, and if it is too far from the plate the preheat is not concentrated on the surface, giving an uneven cut edge and a heavily melted top edge.
Use the nozzle maker's chart for the plate thickness and fuel gas rather than guessing. Too fast a cutting speed gives angled drag lines and slag on the bottom edge. Check the holder and rack are clean and free to move, and that the torch is locked so it cannot drift.
How should I route and support the torch cable?

The torch cable or bundle has weight and stiffness, and it can pull the torch out of line, snag on the track or surroundings, and interrupt the weld. A cable support bracket on the carriage, where the maker offers one for your model, helps to carry that weight.
Fit the support so the cable has enough slack for the whole length of travel, keep it clear of the drive and the hot work, and check it as the carriage moves through the full run before you strike the arc. Inspect cables regularly for breaks and abrasion, and replace any that are damaged.
How do I look after the accessories and clamps?

One carriage maker's manual says to clean dust and spatter off regularly, paying attention to the drive gear and wheel assemblies, and to lubricate occasionally, with a dry lubricant preferred and even light machine oil better than none. Apply the same habit to racks, slides and clamp threads so the adjusters stay free.
The same manual calls for a full strip-down inspection at least once a year: clean, grease and inspect moving parts for wear, check cables for breaks and abrasion, replace damaged or worn parts and check that fastenings are tight. Look over arms, clamps and threads before each job, and replace anything that no longer locks firmly.
