    Rapid Ref : GP-250-M

    Gullco Programmable Rotary Weld Positioner
    GP-250-M

    Select Option
    Prices From £4364.00 ex VAT
     Buy in 3 easy interest free payments of £1280.33† with

    The GP-250-M Welding Positioner is a positive drive rotary turn table complete with a mounting flange, drive and tilt mechanism and Microprocessor pulse width modulation motor control. A low-voltage permanent magnet motor and gearhead power unit assembly drives the welding positioner. The microprocessor motor control enables the operator interface of start, stop, clockwise rotation, neutral, counter clock-wise rotation and infinitely variable control of the speed, within the range of the positioner model.

    The weld positioner's rotation speed is electronically controlled using an optical tachometer located on the back of the gear motor. Speeds within the range of the model are infinitely variable in both clockwise and counter clockwise directions through a rotary speed adjustment potentiometer located on the remote control. Table tilt is manually set at any desired angle, from 0° through 90°, quickly and easily. Safety while using the positioner is greatly enhanced with Gullco’s low voltage (24V) control and power supply system. Positioner complete with table tilt manually set at any position through 90° with positive lock. Mounting plate with tapped holes for either a 12” (305mm) round table with six (6) radial slots, or a Gullco WPG-250 gripper. Alternately, above table and gripper can be mounted together on the positioner mounting plate.

    This model includes a programmable remote control with LED readout and provides the following features:

    • Infinitely variable rotation speed within the model’s speed range
    • Forward/neutral/reverse switch
    • Run/stop switch
    • Programmable microprocessor providing adjustable positioning timing cycles, amount of weld rotation, weld on/weld off through 360° and a signal to activate a pneumatically operated weld gun holder and wire feed arc activation

    Product Details

    Specification

    Rotational Speed: 0.27 - 4.63 RPM
    Vertical Table Loading at 3" C of G: 68Kg
    Horizontal Table Loading: 132Kg
    Table Rotation: 0° through 90°

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    Related Items

    Weld Positioning Equipment FAQs

    Straight answers to the questions people ask most when choosing and using a welding positioner.

    What is a welding positioner and what is it used for?icon-minus-redicon-plus-red

    A welding positioner holds the workpiece and turns it, so you can weld in a comfortable, favourable position instead of moving around the work. The most common type is the rotary positioner, a powered turntable or faceplate that rotates round parts such as pipes, flanges, tanks and shafts under a stationary torch.

    This gives more even welds, better control of the weld pool and less operator fatigue, and it makes circumferential welds much easier. It also suits automated welding and cladding, because the work moves at a steady, repeatable speed.

    How do I choose the right capacity for a positioner?icon-minus-redicon-plus-red

    Capacity is the weight of work a positioner is rated to carry, but the rating depends on how the load sits on the table. A load centred on the axis of rotation is the easy case. If the centre of gravity is offset from the centre, or the table is tilted, the positioner can safely carry less.

    The maker normally gives ratings for different offsets and angles, so check these against your heaviest and most awkward workpiece, and allow a good margin. Remember to include any fixtures, chucks and clamps in the weight.

    What is a hollow centre or through hole in a positioner for?icon-minus-redicon-plus-red

    A positioner with a hole through the centre of the table lets the work pass through, or lets you feed cables, hoses and gas lines through. It is useful for long pipes and shafts that extend through the table, and for supplying a purge gas to the inside of pipework while you weld.

    If your work is long or you need to purge the inside of a pipe, choose a positioner with a hole large enough for what you need to pass through it.

    How do I hold the work on a positioner?icon-minus-redicon-plus-red

    Work can be held with a chuck, clamps, bolted fixtures, or purpose-made tooling. A self-centring chuck suits round parts such as pipes and bars, and a quick-action chuck makes loading and unloading faster. T-slotted tables allow clamps and fixtures to be bolted down.

    Whatever you use, the work must be held securely and as close to the centre as possible, because the turning load can throw the part off if it is loosely held. Check the grip each time, and make sure fixtures are heavy enough for the work and heat.
