    Rapid Ref : 108010-SET

    HMT CarbideMax 80 TCT Broach Cutter 6 Piece Set (18, 22, 24, 26, 28, 30mm) & 2 Pilot Pins
    108010-SET

    Click here to see what's included

    £411.32  EX VAT
    SSP Suggested Selling Price = £483.90  YOU SAVE £72.58
     Buy in 3 easy interest free payments of £137.11† with

    The CarbideMax 80 Series will broach up to 75mm thickness of metal: 4X LONGER LIFE AND 15% FASTER CUT THAN HSS CUTTERS.

    Tungsten Carbide, one of the hardest materials used for cutting tools, can drill through the toughest steels. HMT CarbideMax TCT Broach cutters are tipped with individually brazed cutting teeth of the highest quality tungsten carbide. They are designed with an elaborate cutting geometry, resulting in faster, quieter, easier drilling and chatter-free performance. Furthermore, because the teeth of the cutter are doing all of the hard work, less strain is put on the wall of the cutter. Therefore, the thinner wall means less metal is removed, giving a faster cut.

    HMT CarbideMAX TCT 80 Cutters FAQs

    Straight answers to the questions people ask most when choosing and using deep 80 depth tungsten carbide tipped broach cutters.

    What is a deep annular cutter for?icon-minus-redicon-plus-red

    A broach (annular) cutter removes a ring of metal and leaves a solid slug, which is much more efficient than drilling a full-diameter hole. A deep cutter has a long cutting depth, measured in millimetres.

    It is intended for thick plate, heavy structural sections, stacked material and deep cuts that shorter cutters cannot reach. It is used in a magnetic drill or similar rigid machine. Check the data plate and manual for your own machine to confirm the depth and diameter it is rated for.

    Does a deep cutter need a special pilot pin?icon-minus-redicon-plus-red

    Yes. Pins are made for specific depth series and diameter ranges, and a deep cutter needs a pin of the right length and fit. Some deep cutters use a one-piece pin design.

    Check the diameter range and series on the pin against your cutter. A wrong pin may not eject the slug, may not seat properly or may leak coolant.

    What machine do I need?icon-minus-redicon-plus-red

    A deep cutter needs a powerful, rigid magnetic drill with enough stroke to travel the full depth, a strong magnet and a sound spindle. Deep cuts at large diameters create high torque.

    The magnetic base must sit on clean, flat steel that is thick enough to hold firmly. Check the shank type fits your machine and use the safety strap or chain provided.

    Why do deep cuts need extra attention to coolant?icon-minus-redicon-plus-red

    The deeper the cut, the harder it is for fluid to reach the teeth and the more heat is generated. Without enough lubrication the teeth overheat, the swarf welds to the cutter and the life of the cutter drops sharply.

    Use suitable cutting fluid fed through the pilot pin, keep the reservoir topped up and watch that flow does not stop during the cut.
