    Rapid Ref : 603060-5SET

    HMT VersaDrive 90° Countersink InsertFoam 5 Piece Set (12.4 - 31mm)
    603060-5SET

    Click here to see what's included

    £281.22  EX VAT
    SSP Suggested Selling Price = £330.85  YOU SAVE £49.63
     Buy in 3 easy interest free payments of £93.74† with

    This product is included in the latest promotion from HMT! Valid until December 21st, save £181.85 with this limited time offer. HMT OD26 VersaDrive 90° Countersink InsertFoam 5 Piece Set (12.4 - 31mm)

    Fast, Efficient Countersinking & Deburring 90° point angle for Countersunk Bolt Heads.

    90° point angle for Countersunk Bolt Heads. Safer use with minimal kickback, especially hardened for impact wrench use. High-grade tool Steel with ground flutes for high accuracy & long life. GoldMax low friction Titanium Coating to stop heat burnout. High Strength, Non-slip shank design.

    Product Details

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    HMT Countersinks FAQs

    Answers to common questions about choosing and using countersinks for magnetic drills, drill presses and power drills.

    How large should the countersink diameter be for a given screw?icon-minus-redicon-plus-red

    The countersunk diameter at the surface should be slightly larger than the maximum diameter of the screw head, so the head can seat fully and finish flush. The allowance needed is small, so use the screw maker's head dimensions or a fastener table rather than guessing.

    The clearance hole must already be the right size for the screw shank, and the countersink cutter must be big enough to cut the full recess diameter. For a pattern of holes, trial one on an offcut of the same material and thickness, then check the screw sits as intended before committing to the job.

    What is the difference between a countersink and a counterbore?icon-minus-redicon-plus-red

    A countersink cuts a cone-shaped recess that matches a countersunk (flat head) screw, so the head sits flush. A counterbore cuts a cylindrical recess with a flat bottom, which is what a socket head cap screw or a bolt head with a washer needs.

    Countersinks are also used to chamfer or deburr the edge of a drilled or tapped hole, which gives a lead-in for a tap or screw and removes sharp edges. If you only need to break an edge, a countersink is the usual tool; if the fastener has a flat-underside head that must be recessed, you need a counterbore.

    What safety precautions should I take with loose clothing, hair and gloves when countersinking?icon-minus-redicon-plus-red

    Countersinking uses rotating tools, so entanglement is a real risk. The HSE advises avoiding loose or baggy clothing, tying back or covering long hair, and avoiding jewellery, including rings, when operating engineering machinery. It also says many serious workshop accidents could be avoided if gloves were not worn near rotating machinery such as drills.

    Follow the machine maker's instructions and your own risk assessment. Hold or clamp the work securely so it cannot spin with the cutter, and keep hands clear of the rotating tool.

    What is a Weldon shank, and how should I fit the countersink in a magnetic drill?icon-minus-redicon-plus-red

    A Weldon shank is a round shank with one or more flats machined on it. A screw in the machine's holder or arbor bears on the flat, which stops the tool from twisting or pulling out under load.

    Make sure the shank size and flat style match the holder, that the shank is fully inserted, and that the screw is tightened onto the flat before each use. Some machines with quick-change fittings need an adapter for standard Weldon shanks, so check before buying. Never use a countersink in a holder it does not fit, and always follow the magnetic drill maker's manual for fitting, clamping and the speed range.
