    Rapid Ref : 308020

    HMT VersaDrive Oversized Galv ImpactaTap
    308020

    Select Option
    Prices From £31.58 ex VAT

    HMT VersaDrive Heavy Duty Impacta-Drill Taps are primarily designed to be adapted for use with a reversible Magnet Drill to drill and tap heavy plate in 1 easy operation. However, they can also be adapted with an impact wrench to enlarge and tap existing holes. Due to the high rotational torque generated by larger thread sizes, Heavy Duty Impacta-DrillTaps are not recommended for use in a standard drill chuck.

    Ground Flute Twist Drill Creates the perfect Tapping Hole. Safer Tapping with Minimal Kickback; specially hardened for impact wrench use. High-grade tool Steel with ground flutes for high accuracy & long life. GoldMax low friction Titanium Coating to stop heat burnout. High Strength, Non-slip shank design.

    Product Details

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    HMT Taps FAQs

    Answers to common questions about choosing and using taps and thread chasers for cutting and restoring internal threads.

    What is the difference between a tap and a thread chaser?icon-minus-redicon-plus-red

    A cutting tap makes a new thread by removing metal from a plain drilled hole. A thread chaser is designed to clean up and re-form a thread that already exists, following the existing thread path without cutting away much material.

    For threads that are dirty, burred or lightly damaged, a chaser is usually the gentler first choice. A cutting tap can remove too much thread material and weaken the thread, so it suits new holes. If a thread is badly stripped, replacing the part or fitting a threaded insert is normally the better repair.

    Why do taps break, and how can I avoid it?icon-minus-redicon-plus-red

    A tap is hard and brittle, and it rarely breaks without warning. Common causes are a hole drilled too small, chips packing in the flutes, the wrong tap style for a blind or through hole, hitting the bottom of a blind hole, side loading from a tap that is not square, and too little lubricant.

    Check the tap drill size, keep the tap square, use suitable cutting fluid and clear the chips by backing off regularly. Stop if the tap suddenly becomes harder to turn, as forcing it is how most taps snap.

    How do I choose the right drill size before tapping?icon-minus-redicon-plus-red

    A tapped hole starts with a drilled hole, called the tap drill, which is smaller than the thread's nominal size so that metal remains to form the thread. For metric coarse threads a common workshop rule is the nominal diameter minus the pitch, and a finer pitch therefore needs a larger drill than a coarse pitch of the same diameter.

    The rule is only a quick estimate, so use a tap drill chart for your thread and the maker's guidance, especially for fine, inch, pipe or special threads. A hole that is too small overloads the tap, while one that is too large leaves a shallow thread with less holding strength. Drill square and remove any burr at the entry.

    Why do some taps come oversize for galvanised work?icon-minus-redicon-plus-red

    When a part is galvanised, the zinc coating adds thickness to the threads, which can increase the diameter of a bolt thread. The nut or tapped hole therefore needs to be cut slightly larger so that the coated bolt can be assembled. This is called overtapping, and it is why oversize taps exist.

    An oversize tap is not a general replacement for a standard tap, because a nut tapped oversize will fit loosely on an uncoated bolt. Check the maker's marking and the requirement for your fastener before choosing.
