Machine TIG Torches FAQs
Answers to common questions about machine (mechanised) TIG torches fitted to carriages, positioners and automated welding heads.
What is the difference between a machine torch and a hand-held TIG torch?

A machine torch is built to be clamped in a carriage, positioner, slide or robot arm instead of being held by a welder. It normally has a straight, rigid barrel-style body that suits a clamp, and no handle or trigger switch, because the welding machine or controller starts and stops the arc.
The standard for arc welding torches covers mechanically guided and liquid-cooled types as well as manual ones, so machine torches are a recognised type in their own right. Check the body diameter, connections and cooling type against your mounting and power source.
Do I need eye protection and screens around an automated TIG station?

Yes. The arc gives off ultraviolet, visible and infrared radiation whether it is started by hand or by a controller. HSE describes arc eye as an injury to the front of the eye after exposure to welding radiation, usually becoming painful and red a few hours later. UV can also cause sunburn-like reddening of skin.
Face and eye protection with a suitable filter, covered skin, and non-reflective screens for anyone nearby are the usual controls. Anyone setting up or watching the torch while the arc is on needs the same protection as a welder. Follow your risk assessment.
Does mechanised TIG welding still produce fume I need to control?

Yes. Automation does not remove welding fume, and HSE states that both acute and chronic health risks are associated with it. Fume is best controlled at source, for example with local exhaust ventilation positioned close to the weld, rather than relying on respiratory protection alone.
What suits your set-up depends on the material, the welding time and the enclosure, so it needs to come from your risk assessment (COSHH). Check any extraction is positioned so it does not pull shielding gas away from the weld pool.
What should I check on the cable, hoses and connections of a machine torch?

Check the torch, leads and connectors for damage at regular intervals. Welding safety guidance advises that welding leads, connection devices and the torch should be checked for fitness for use, with damaged or worn parts repaired or replaced, and that electric shock is the principal risk in arc welding.
On a machine torch, also look at how the cable and hoses move with the carriage or positioner. Avoid tight bends, kinks, trapped hoses and strain on the connectors. Isolate the machine before touching connections, and use the maker's instructions to tell you what to inspect.
