ArcReach welding technology minimizes the non-value-added time spent walking to and from the power source and maximizes arc-on time, weld quality and jobsite safety. When operators have complete control at the feeder or remote, even hundred metres away from the power source, it minimizes downtime and maximizes productivity, while improving operator safety and delivering high quality welds.
Specification
- Input Power: Operates on open-circuit voltage and arc voltage: 14–48 VDC/ 110 max.OCV
- IP Prating: IP23
- Input Welding Circuit Rating: 330 A at 60% duty cycle
- Wire Feed Speed: 1.3–19.8 m/min. dependent on arc voltage
- Wire Type and Diameter Capacity: Solid wire: 0.6–1.4 mm. Flux-cored: 0.8–2.0 mm
- Max. Spool Size Capacity: 203 mm, 6.4 kg
- Dimensions: H: 324 mm x W: 184 mm x D: 457 mm
- Net Weight: 13 kg
