Orbitalum Accessories for BRB / REB machines FAQs
Answers on the clamping, lubrication and air-supply accessories used with portable pipe end preparation machines.
How does inside-diameter clamping hold the pipe or tube?

Portable pipe end preparation machines of this type are clamped from the inside. A clamping head fitted with a set of clamping wedges locates in the open end of the pipe and expands against the bore, so the machine is centred on the inside of the pipe. Makers describe the pipe dimension as quick to set for each wedge set.
Because the clamp works off the bore, the inside diameter matters more than the outside diameter when you choose the wedge set. Check that the range on the data plate or in the manual covers the pipe, and keep loose scale, swarf and burrs out of the bore so the wedges seat properly.
Why is the bevel angle and finish important before welding?

Bevelling the pipe ends gives access to all parts of the joint, so the weld can fuse properly right through. Single-sided joints need dimensionally accurate preparation and fit-up, the included angle is what matters for access, and if the angle or gap is too small there is not enough room to hold a correct arc length.
The angle, root face and gap that you need are set by your weld procedure and the standard for the job, so check those before you set up the machine. A clean, even, burr-free finish also helps the pipe ends fit together properly, so check the finished prep before you move on.
What are optional clamping wedges for?

Clamping wedges are the parts that actually contact the pipe bore. A standard set covers a stated range of bore sizes, and makers list optional wedge sets specifically for extending that range, each shown against the pipe inside diameter it suits, so the same machine can take larger bores.
Choose them by the inside diameter of the pipe, which depends on the outside diameter and the wall thickness, not by the nominal pipe size alone. Measure the bore if you are unsure, and check the machine's manual for which wedge set matches which bore range. Do not use a set outside its stated range.
Why use cutting fluid when preparing stainless steel?

Austenitic stainless steel work hardens, and its chips carry away little heat, so heat stays at the cutting edge and shortens tool life. Machining guidance says coolant is almost always crucial for these grades. Makers of pipe end preparation machines supply a water-soluble synthetic cutting fluid for this reason, to increase the service life of the cutting inserts.
Use the fluid the machine maker recommends. Keep it off the surfaces that will be welded, and clean the pipe end as your weld procedure requires, because the weld preparation must be clean. How much to apply depends on the machine and the job.
