    Rapid Ref : 790046188

    Orbitalum Support Disc for Saw Blade/Bevel Cutter Combinations, RA & GF Machines
    790046188

    £42.00  EX VAT
     Buy in 3 easy interest free payments of £14.00† with

    GF Sawblade / Bevel Cutter Combinations FAQs

    Answers on choosing and using combination tools that cut tube and prepare the end for welding or press fittings in one go.

    What is the difference between a weld-prep combination and a press-fitting combination?icon-minus-redicon-plus-red

    A weld-prep combination cuts the tube and bevels the end in one pass, leaving a groove shape for a butt weld. A press-fitting combination is intended for tube that will be joined with a mechanical press fitting, where the main need is a clean, square cut and a smooth edge rather than a welding groove.

    The two are not interchangeable, because the edge each one leaves is different. Read the product description and the machine manual to see exactly what edge a particular tool produces, and the fitting maker's instructions to see what the tube end must be like.

    Do I still need to deburr after a press-fitting cut?icon-minus-redicon-plus-red

    Usually yes, unless the tool maker states the cut needs no further work. Press fitting makers say tube should be cut square and then deburred inside and outside, because burrs and sharp edges can damage the sealing ring when the tube is pushed in and lead to leaks.

    Also check that the tube is clean and round, and keep swarf out of the tube as far as you can. Always follow the specific fitting maker's instructions on preparation and insertion depth, as details vary.

    When does a tube end actually need a bevel?icon-minus-redicon-plus-red

    It depends on the wall thickness and the welding procedure. Thin-wall tube welded by orbital welding is commonly joined as a square butt with only a clean, square cut, while thicker walls normally need a prepared groove (such as a V or J shape) so that the weld can fully penetrate. There is no single wall thickness that suits everyone.

    Your welding procedure specification, or the welder or inspector responsible for the job, should state the required end preparation. Use a weld-prep tool only where the procedure calls for a bevel.

    What is the bevel angle compared with the included angle?icon-minus-redicon-plus-red

    The bevel angle is measured on one side of the joint, from the square end of the tube. The included angle is the angle between the two prepared faces once the tubes meet, and for a V preparation it is twice the bevel angle. So a bevel of 30 degrees on each tube gives an included angle of 60 degrees.

    Common pipe V bevels are around 30 to 37.5 degrees, but the correct figure is whatever your welding procedure specifies. Check the angle quoted on the tool matches that figure before buying.
