BRB 2 Tool Holders FAQs
Answers to common questions about tool holders for portable orbital pipe and tube end-preparation machines.
How do I choose the right tool holder for the weld preparation I need?

Start with the joint you want to produce: a square (I-seam) face, a V bevel, or a curved J or U preparation. Each needs a differently shaped cutting edge, so the holder and its bit are normally chosen as a pair for that preparation.
Then check the tube or pipe wall thickness, outside diameter and material, plus how the machine clamps the work. The weld procedure or your welding engineer should say which preparation and angle are required. If you are unsure, our team can help you match a holder to the job.
What is the difference between I-seam, V and J (U) preparations?

An I-seam is a plain square-cut face butted together; it is not strictly a bevel and suits thin walls. A V bevel is a straight angled face that forms a V when two ends are joined. A J (or U) preparation has a curved lower face and a land, so it needs less weld metal on thicker walls and is often preferred for orbital welding.
J preparations are harder to machine than V bevels, which is why a dedicated holder and bit is used. The right choice depends on wall thickness, material and the weld procedure.
Why does the bit sometimes chatter or leave a rough finish?

Chatter usually comes from something loose, worn or sticking out too far. Common causes are a worn cutting edge, a bit not seated or tightened properly, too much overhang from the holder, feed that is too heavy, or a workpiece that is not clamped firmly.
Keep the bit projecting as little as the job allows, make sure the tube is held securely, and replace dull bits rather than pushing on. If chatter continues, reduce the feed and check the holder seat for wear.
Do I need different tooling for stainless steel tube?

Stainless steels, particularly austenitic and duplex grades, work-harden when the tool rubs rather than cuts. Use sharp bits with suitable geometry for the material, keep a steady feed rather than hesitating, and change bits regularly because a worn edge makes work hardening worse.
A generous flow of suitable cutting fluid is also recommended. Keep the tool overhang short and clamp the tube firmly. Check the maker's guidance for your bit and material, and try a test piece first.
