100 Series Parts FAQs
Spare protection plates, filters, headbands, sweatbands, magnifying lenses and neck and ear covers for an auto-darkening welding helmet, and how to choose the right ones.
How do I work out which spare parts fit my helmet?

Start with the helmet itself. Look for the model marking on the shell, the filter and the headgear, and check the user manual, which normally lists the compatible spares. If you still have the old part, note any part number printed or moulded on it and measure its width and height.
The HSE says PPE should be maintained using the correct replacement parts and following the manufacturer's replacement schedule. Plates, filters and headgear from one helmet series often do not fit another, even when they look alike, so do not rely on a 'looks the same' match. Our team can help you match a part if you send the details from the helmet.
When should I replace a protection plate?

There is no single interval that suits everyone, because it depends on the process, the amount of spatter and how often you weld. Inspect the plates before each shift. Replace an outside plate once it is pitted, scratched, cracked, hazy or too dirty to clean with a soft cloth, and replace an inside plate when it is damaged or when spatter stops you seeing clearly.
A marked outer plate can also block light from the filter sensors and make an auto-darkening filter behave oddly. Replacing a plate early is better than damaging the filter behind it. Always follow the helmet manual.
What do the four numbers in an optical class marking on a replacement filter mean?

Auto-darkening filters are usually marked with four digits in the form 1/1/1/2. In the older European marking the digits are the optical class, the diffusion of light class, the variation in luminous transmittance class and the angle dependence of luminous transmittance class. Each is graded from 1 to 3, with 1 the best.
The older standard has been withdrawn and replaced by a newer international standard series, so newer filters and manuals may be marked differently. When you replace a filter, compare its markings with the old one and check the maker's manual for the shade range and size, as the digits alone do not tell you whether it fits your helmet.
How do I choose the power of a magnifying lens?

A magnifying lens, sometimes called a cheater lens, sits behind the filter and makes close detail easier to see. Strength is given in diopters, and the higher the number, the closer you need to hold the work. A rough method is to find the reading-glasses strength that gives a sharp view at your usual working distance and use that as a starting point.
Fine work such as TIG often suits a stronger lens than rough work done at arm's length. Try a lens in your normal position before ordering several, and make sure it is sized for your helmet's filter holder. If you wear prescription glasses, ask your optician for advice.
