The PATON ProMIG 270 is designed for direct current welding of a wide range of materials in MIG/MAG, MMA
and Lift TIG modes. These PATON ProMIG welding machines are designed for professional use. The welding current
source can be used separately from the wire feeding unit to provide ease of operation in MMA and TIG
modes and verify the machine's compliance with safety requirements in some welding cases.
Specification
| Mains Voltage: |
380/400V 3ph |
| Welding Current Range: |
12 - 270A |
| Duty Cycle: |
270A at 70%, 225A at 100% |
| Maximum Power Consumption: |
11.4kVA
|
| Dimensions (L x W x H): |
540mm x 360mm x 400mm
|
| Weight: |
23.5kg
|
| Protection Class: |
IP33
|
Perfect For
- Professional Workshops
- Agricultural Work
- Vehicle Repair
