The PATON ProMIG-500 400V welding machine is designed for semi-automatic welding using the MIG/MAG process with shielding gases and protective mixtures, manual arc welding using the MMA method, and arc welding in an argon shield using the TIG method with DC current.
Specification
| Mains Voltage: |
380/400 3ph |
| Welding Current Range: |
16 - 500A |
| Duty Cycle: |
500A at 70%, 420A at 100% |
| Maximum Power Consumption: |
29kVA
|
| Dimensions (L x W x H): |
510mm x 180mm x 385m
|
| Weight: |
36.7kg
|
| Protection Class: |
IP23
|
Perfect For
- Metallurgy
- Metalworking
- Shipbuilding
- Ship repair
