The MasterTIG-200 AC/DC industrial inverter welding machine is designed for welding with constant, alternating, pulse, and pulse-constant currents on a wide range of materials: aluminium, aluminium alloys, steel, non-ferrous metals, and copper alloys (mainly in TIG mode). The machine can also operate in spot welding mode (SPOT) and with coated electrodes (MMA mode). In CLEAN mode, the machine cleans stainless-steel welding parts and their seams of oxides and discolouration, and polishes stainless-steel products. To operate in CLEAN mode, a separate electrolytic solution for passivating high-alloy steels must be purchased. Without it, cleaning and polishing stainless steel using this function is not possible. The MasterTIG-200 features a 40% (DC) and 50% (AC) duty cycle, as well as a 3-year warranty.
Specification
| Mains Voltage: |
230V |
| Welding Current Range: |
5 - 200A |
| Duty Cycle: |
DC – 40%, AC – 50%
|
| Nominal Power Consumption: |
6.3kVA
|
| Dimensions (L x W x H): |
465mm x 150mm x 350mm
|
| Weight: |
12.5kg
|
| Protection Class: |
IP23 |
Perfect For
- Automotive & Aerospace
- Pipework
- General Fabrication
