The PATON 8S welding machine cooler is a multi-purpose cooling device designed to provide highly efficient cooling for welding torch accessories and plasma torches. The cooler can be used for both welding apparatus and plasma cutters.
The PATON 8S welding machine cooler provides reliable cooling for the handle operating at high currents (above 300A for semi-automatic welding machines and above 140A for TIG welding). It is an indispensable part of continuously operating welding equipment. The cooler holds up to 8 litres of coolant and ensures that it is circulated in a closed system with high capacity (delivering fluid to a height of 10 metres) and flow rate (up to 6.5 l/min).
Specification
| Mains Voltage: |
230v |
| Power, W |
270 |
| Cooling power, kW, at 1L/min: |
1 |
| Load duration, % |
100 |
| Rated current consumption, L |
1,23 |
| Coolant tank volume, L |
8 |
| Maximum feed L/min |
6,5 |
| Dimensions (L x W x H): |
522mm x 267mm x 382mm
|
| Weight: |
16kg
|
| Protection Class: |
IP21 |
