    Rapid Ref : 308010-SET3

    HMT VersaDrive ImpactaTap InsertFoam 7 Piece Set (M6, M8, M10, M12, M16, M20, M24)
    308010-SET3

    Click here to see what's included

    £375.57  EX VAT
    SSP Suggested Selling Price = £441.85  YOU SAVE £66.28
     Buy in 3 easy interest free payments of £125.19† with

    FIFTEEN TIMES FASTER THAN HAND TAPPING.

    VersaDrive ImpactaTaps perform best when adapted with an Impact wrench for Tapping through holes. However, they can also be adapted for use in a reversible Magnet Drill or even used with any standard Hand Tap wrench.

    Fast Tapping with Minimal Kickback; Specially hardened for Impact Wrench use. Chipbreaker action is for Automatic chip clearance when Impact Tapping. Unique Dual-Point Starting Angle for easy alignment and fast cut. High-Grade Tool Steel with Ground Flutes for high accuracy & long life. GoldMax low-friction Titanium coating to stop heat burnout. High Strength, Non-slip Shank Design.

    Product Details

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    HMT Taps FAQs

    Answers to common questions about choosing and using taps and thread chasers for cutting and restoring internal threads.

    What is the difference between a tap and a thread chaser?icon-minus-redicon-plus-red

    A cutting tap makes a new thread by removing metal from a plain drilled hole. A thread chaser is designed to clean up and re-form a thread that already exists, following the existing thread path without cutting away much material.

    For threads that are dirty, burred or lightly damaged, a chaser is usually the gentler first choice. A cutting tap can remove too much thread material and weaken the thread, so it suits new holes. If a thread is badly stripped, replacing the part or fitting a threaded insert is normally the better repair.

    Should I use a spiral flute tap or a spiral point tap?icon-minus-redicon-plus-red

    The choice depends on where the chips can go. A spiral point tap pushes chips ahead of it, so it suits through holes where chips can leave the far side. A spiral flute tap draws chips back out along its flutes, so it suits blind holes.

    Using a spiral point tap in a blind hole can pack chips at the bottom until the torque rises sharply and the tap breaks. Spiral flute taps are generally not recommended for very hard materials, so check the maker's guidance for the material you are tapping.

    Why do taps break, and how can I avoid it?icon-minus-redicon-plus-red

    A tap is hard and brittle, and it rarely breaks without warning. Common causes are a hole drilled too small, chips packing in the flutes, the wrong tap style for a blind or through hole, hitting the bottom of a blind hole, side loading from a tap that is not square, and too little lubricant.

    Check the tap drill size, keep the tap square, use suitable cutting fluid and clear the chips by backing off regularly. Stop if the tap suddenly becomes harder to turn, as forcing it is how most taps snap.

    How do I choose the right drill size before tapping?icon-minus-redicon-plus-red

    A tapped hole starts with a drilled hole, called the tap drill, which is smaller than the thread's nominal size so that metal remains to form the thread. For metric coarse threads a common workshop rule is the nominal diameter minus the pitch, and a finer pitch therefore needs a larger drill than a coarse pitch of the same diameter.

    The rule is only a quick estimate, so use a tap drill chart for your thread and the maker's guidance, especially for fine, inch, pipe or special threads. A hole that is too small overloads the tap, while one that is too large leaves a shallow thread with less holding strength. Drill square and remove any burr at the entry.
