    Rapid Ref : 501040-SET7

    HMT VersaDrive Impact Reamer InsertFoam 5 Piece Set (9/16, 11/16, 13/16, 15/16, 1-1/16")
    501040-SET7

    Click here to see what's included

    £443.36  EX VAT
    SSP Suggested Selling Price = £521.60  YOU SAVE £78.24
     Buy in 3 easy interest free payments of £147.79† with

    KEEP THE JOB MOVING WHEN A CONNECTION HOLE IS UNDERSIZED.

    VersaDrive Reamers perform the fastest and with less kickback when adapted with an Impact wrench for enlarging holes in steel plate up to around 20mm thick. However, they can also be used in any standard 1/2" cordless or pistol drill chuck or adapted for a slow-speed Magnet Drill. Ideal for use on plate heavier than 20mm thick. VersaDrive reamers are 'Not recommended' for use with laser or plasma cut holes. Heat-affected holes can be enlarged using the VersaDrive reamer with a slow-speed magnet drill.

    Precision 6-Flute design for a smooth cut on structural steel. Safer reaming with minimal kickback, specially hardened for impact wrench use. High-grade tool Steel with ground flutes for high accuracy & long life. GoldMax low friction Titanium Coating to stop heat burnout. High Strength, Non-slip shank design.

    Product Details

    HMT Reamers FAQs

    Answers to common questions about choosing and using reamers for enlarging and aligning holes in steelwork.

    What is a reamer used for on steelwork?icon-minus-redicon-plus-red

    A reamer enlarges and cleans up an existing hole to a more accurate size and a smoother finish. In structural steelwork it is commonly used during erection, when plates or sections have been bolted loosely together and the holes do not quite line up, so that a bolt can pass through without damaging its thread.

    The result is a slightly larger or elongated hole, so it is a tool for small, local misalignment rather than a general way to make holes. Check the connection requirements for your job before reaming.

    Can a reamer fix a hole that is in the wrong place?icon-minus-redicon-plus-red

    No. A reamer follows the hole that is already there, so it will not correct a hole that is off position or not straight. It can deal with small, local misalignment between plies, but only by removing the minimum material needed.

    If holes are badly out, reaming is the wrong answer and the connection may need to be reviewed by the person responsible for the design. Do not try to fill mislocated holes by welding without that advice.

    Do I need cutting fluid when reaming?icon-minus-redicon-plus-red

    In most cases, yes. Cutting fluid lubricates the cut, cools the tool, helps clear chips and generally gives a better finish and longer tool life. Reaming dry can leave a rougher hole and may give an oversize one.

    The type of fluid can affect both finish and final hole size, and the effect varies with the fluid, the material and the reamer. Use the fluid the reamer maker recommends for your material, and where the size is critical, try it on a test piece and measure the result before reaming the job.

    What eye protection should I wear when reaming?icon-minus-redicon-plus-red

    Wear eye protection suited to the job. The HSE lists working with power-driven tools, where debris or chippings may fly into the face, as a case where eye protection is needed, and says it should be appropriate for the task and fit the wearer properly.

    Safety glasses with side protection are the minimum for most reaming; goggles or a face shield may be better where chips are thrown. Do not use compressed air to blow swarf away, because it can bounce back into the eyes. Use a brush or a vacuum instead, with the tool stopped.
