BM25S-X JEI Steelbeast BM-25S Stainless Steel Plate Beveller
    Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

    Rapid Ref : BM25S-X

    JEI Steelbeast BM-25S Stainless Steel Plate Beveller
    BM25S-X

    Select Option
    Prices From £3450.00 ex VAT
    The Steelbeast BM-25S is a portable, heavy-duty machine designed for efficient bevelling of stainless steel. Equipped with a powerful motor and a face-milling bevelling head, the BM-25S beveller ensures smooth operation and exceptional efficiency. It allows the milling of straight edges with bevel widths up to 25 mm, and its variable spindle speed makes it easy to optimise cutting conditions.

    FEATURES

    • Contamination-free stainless-steel processing
    • Comfort and ergonomics of work.
    • Continuously adjustable bevel angle between 0 and 90 degrees.
    • Single head operates with face milling method.
    • Continuous bevel width adjustment.
    • Powerful electric motor.
    • Milling head is equipped with 5 pcs of 4-sided indexable cutting inserts.
    • Maximum 25 mm bevel width (more than one pass could be required).
    • Electronic speed control between 1800–5850 rpm.
    • Overload protection.

    Product Details

    Voltage: 110/230 V, 50/60 Hz
    Power: 2200 W
    Spindle Rotational Speed (without load): 1800-5850 RPM
    Maximum Bevel Width: 25mm
    Maximum Depth of Cut: 12.5mm
    Bevel Angle: From 0° to 90° (15° to 75° recommended)
    Minimum workpiece thickness: 2mm
    Required Ambient Temperature: 0-40°C
    Weight: 12.5kg

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure
       JEI Steelbeast BM-25 Operator's Manual
