Rapid Ref : BM25S-2 Mfr Ref : BM25S/2

JEI Steelbeast BM-25S Stainless Steel Plate Beveller
BM25S/2 BM25S-2

Select Option

£3450.00 EX VAT

Buy in 3 easy interest free payments of £1150.00^† with

The Steelbeast BM-25S is a portable, heavy-duty machine designed for efficient bevelling of stainless steel. Equipped with a powerful motor and a face-milling bevelling head, the BM-25S beveller ensures smooth operation and exceptional efficiency. It allows the milling of straight edges with bevel widths up to 25 mm, and its variable spindle speed makes it easy to optimise cutting conditions.

FEATURES

Contamination-free stainless-steel processing
Comfort and ergonomics of work.
Continuously adjustable bevel angle between 0 and 90 degrees.
Single head operates with face milling method.
Continuous bevel width adjustment.
Powerful electric motor.
Milling head is equipped with 5 pcs of 4-sided indexable cutting inserts.
Maximum 25 mm bevel width (more than one pass could be required).
Electronic speed control between 1800–5850 rpm.
Overload protection.

Product Details

Voltage: 110/230 V, 50/60 Hz

Power: 2200 W

Spindle Rotational Speed (without load): 1800-5850 RPM

Maximum Bevel Width: 25mm

Maximum Depth of Cut: 12.5mm

Bevel Angle: From 0° to 90° (15° to 75° recommended)

Minimum workpiece thickness: 2mm

Required Ambient Temperature: 0-40°C

Weight: 12.5kg

Brochures & Manuals

BROCHURES & MANUALS

View Brochure

JEI Steelbeast BM-25 Operator's Manual
