GASIQ6290-NFF GasiQ NX/NFF Propane Cutting Nozzle, for Preheating (NFF for Extra Preheating)
    Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

    Rapid Ref : GASIQ6290-NFF

    GasiQ NX/NFF Propane Cutting Nozzle, for Preheating (NFF for Extra Preheating)
    GASIQ6290-NFF

    Select Option
    Prices From £6.37 ex VAT
    Cutting nozzles for preheating. These nozzles are particularly well-suited to cutting scrap with the GasIQ 62-5 torch or the Harris Injector hand-cutting torch.

    Related Items

    Gas Cutting Nozzles FAQs

    Straight answers to the questions people ask most when choosing and using gas cutting nozzles.

    How do I choose the right cutting nozzle size?icon-minus-redicon-plus-red

    Cutting nozzles are sized for the thickness of steel you cut. The nozzle size sets how much oxygen and fuel gas flows, so a bigger nozzle suits thicker plate and a smaller one suits thin sheet. Each maker publishes a chart relating nozzle size to thickness and giving the oxygen and fuel gas pressures to use, and you should work from the chart for your own nozzle type.

    A nozzle that is too large wastes gas and gives a wide, rough cut, and one that is too small cannot cut cleanly through the plate. Choose for the thickness you cut most, and use a different nozzle for much thicker or thinner jobs.

    Will a nozzle fit my cutting torch?icon-minus-redicon-plus-red

    Nozzles are made to fit particular torches. The seat, the thread or nut, and the way the gases are fed all vary, so the nozzle must match the torch type and the maker's range. Torches also differ in how they handle the gases: injector (low-pressure) torches draw the fuel gas in using the oxygen flow, while positive-pressure torches are fed both gases at working pressure, and nozzles for one are not necessarily right for the other. Nozzle-mix designs combine the gases in the nozzle itself.

    Check the torch maker's list of nozzles for your model, or the markings on your existing nozzle, before you buy. If you are unsure, our team can help you identify the right one.

    How do I clean a cutting nozzle?icon-minus-redicon-plus-red

    Switch off the gases and let the nozzle cool, then clear the preheat holes and the central cutting oxygen bore with the correct size of tip cleaner. Push the cleaner straight in and out with a gentle action, use the cleaner sized for that hole, and do not force it. Never use drills, nails or wire, because they ruin the hole.

    Finish by cleaning the outside and the sealing seat with a soft brush and removing any loose dirt. Ports blocked with slag cause a distorted flame, poor cuts and popping, so clean the nozzle whenever the flame looks uneven.

    Why is my gas cut rough, or why is slag sticking to the underside?icon-minus-redicon-plus-red

    Common causes are the wrong nozzle size for the plate, a worn or dirty nozzle, the wrong gas pressures, a travel speed that is too fast or too slow, and holding the nozzle too close to or too far from the plate. Rust, scale and paint on the plate can also upset the cut.

    Clean the nozzle first, then check the pressures against the maker's chart and adjust your speed. Heavy slag on the underside often means you are moving too slowly or have too much heat, while sparks flying up from the top instead of through the plate usually mean the cut is not going right through, because you are moving too fast or using too little oxygen.

    See all 6 questions for this category
