Rapid Ref : GS-WG170DY

GenSet 170A Diesel Engine Driven Welder Generator
GS-WG170DY

£4850.00 EX VAT

Buy in 3 easy interest free payments of £1616.67^† with

Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

Compact and lightweight portable engine driven welder. Equipped with a stage 3,000 RPM Yanmar engine. Asynchronous alternator for enhanced welding current quality, clean and distortion-free waveform. Just like all the GenSet engine driven welders, it is designed to be used as both generator and welder simultaneously. Its simple and smart design allows a practical and easy use.

Warning lights for: battery charger failure
Low oil pressure
Starting battery
Voltmeter
1 x 16A 230V single phase socket
1 x 16A 110V single phase socket
Power output protection
Earth leakage circuit breaker (ELCB)

Product Details

Technical Specifications

Noise Level (LWA)	99 (74dB a 7m)
AC Generator 50Hz	Asynchronous
Single Phase Max. Power	2kVA - 110V
Single Phase Max. Power	4kVA - 230V
Power Factor	Cos 0.8
DC Welding	Electrotechnical current regulation
Duty Cycle @ 60%	140A - 26V
Output Range	40A - 170A
Open Circuit Voltage	90V
Max Welding Rod	4mm
Yanmar Engine	L100 V
Fuel	Diesel
No. Cylinders	1
Power	8.8 HP (6.5kWm)
Displacement	435cm3
Cooling System	Air
Starting System	Electric
Fuel Tank Capacity	5.4l
Fuel Consumption @ 75%	1.5l/h
Insulation Class	H
Ambient Temperature	40ºC
Altitude	1000m
Degree of Protection	IP23
Dimensions (LxWxH)	950 x 480 x 574mm
Dry Weight	148Kg
