Rapid Ref : GS-WG200PH

GenSet 200A Petrol Engine Driven Welder Generator
GS-WG200PH

£3995.00  EX VAT
 Buy in 3 easy interest free payments of £1331.67 with
Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

Compact and lightweight portable engine driven welder. Equipped with a stage 5, 3000 RPM Honda engine. Asynchronous alternator for enhanced welding current quality, clean and distortion-free waveform. Just like all the GenSet engine driven welders, it is designed to be used as both generator and welder simultaneously. Its simple and smart design allows a practical and easy use.

  • Welding with cellulosic electrode
  • Steeples current adjustment
  • Low oil shutdown device
  • Air force control
  • Voltmeter
  • Remote control socket
  • 1 x 16A 230V single phase socket
  • 1 x 16A 110V single phase socket
  • Power output protection
  • Earth leakage circuit breaker (ELCB)

Product Details

Technical Specifications

Noise Level (LWA) 96 (71dB a 7m)
AC Generator 50Hz Asynchronous
Single Phase Max. Power 2kW - 110V
Single Phase Max. Power 3.6kW - 230V
Power Factor Cos 0.8
DC Welding Electrotechnical current regulation
Duty Cycle @ 60% 150A - 26V
Output Range 30A - 200A
Open Circuit Voltage 70V
Max Welding Rod
4mm
Honda Engine GX 390 3000RPM
Fuel Petrol
No. Cylinders 1
Power 11 HP (8.2kWm)
Displacement 390cm3
Cooling System Air
Starting System Recoil
Fuel Tank Capacity 6.1l
Fuel Consumption @ 75% 3.3l/h
Insulation Class H
Ambient Temperature 40ºC
Altitude 1000m
Degree of Protection IP23
Dimensions (LxWxH) 720 x 480 x 515mm
Dry Weight 96Kg
