CK300 Torch Parts FAQs
Practical answers on choosing, fitting and looking after the torch body, hoses, power cable and back cap for a large water-cooled TIG torch.
Why must coolant be flowing before I strike an arc?

In a water-cooled torch the coolant carries heat away from the power cable and torch head. A torch maker's manual warns that insufficient coolant flow can cause permanent damage to the torch, and tells the user to check the cooling function before use. Liquid-cooled cable assemblies can also leak if they overheat.
Before welding, switch the cooler on, check the coolant level and look for coolant returning to the cooler and for leaks at the fittings. Poor flow can come from a blocked filter, a kinked line, crossed connections or a clogged fitting. If the cooler has a flow switch or alarm, never bypass it.
Why does the power cable inside a water-cooled hose fail, and which way should the coolant flow?

In many water-cooled torches the power cable runs inside the coolant return hose, so coolant passes along it on its way back to the cooler. A torch maker's troubleshooting guide says that when water-cooled leads wear out quickly you should verify the coolant flow direction: the return flow must be on the power cable lead. Another maker's manual warns that if the coolant connections are crossed the torch may overheat.
Constant flexing can also wear the cable. A cable that runs hot, feels stiff or leaks at the fitting should be checked and normally replaced rather than patched.
What are the signs that a hose or power cable needs replacing?

Look for cracking, ballooning or bubbling, thinning walls, cuts, scuffed outer covers, stiffness and drips at the fittings. Welding-equipment makers' manuals say hose packs should be undamaged and securely connected, damaged parts should be replaced immediately, and a leaking hose pack should be replaced because a leak can cause high-frequency flashover.
A cable that gets hot, a hose that kinks easily or coolant that returns weakly can also point to a worn or partly blocked assembly. Do not tape a leaking hose; replace the whole hose or cable assembly.
How do I check for gas leaks in the torch and hoses?

Air drawn into the gas stream causes porosity. A welding-equipment maker's troubleshooting guide lists a defective gas hose or loose connection among the causes and says to check hoses and connections for leaks. Common places are the back cap O-ring, the torch head seals, loose fittings and a damaged or kinked gas hose.
With the gas on, brush leak-test solution or soapy water on each connection and look for bubbles, or close the gas at the regulator and watch for a pressure drop. Wipe the solution off afterwards and replace any damaged hose rather than taping it.
