Torch bodies, handles, back caps and cable and hose sets for a water-cooled TIG torch: how to pick the right part and look after it.
Air-cooled torches can overheat during long welding runs, and the usual answer is either to let them cool or to move to a water-cooled torch. Water-cooled torches are therefore generally chosen for sustained higher-current work and long arc-on times.Air-cooled torches are lighter and simpler because they need no cooler. A water-cooled torch needs a suitable cooler connected to the machine and the hoses kept in good order. The current at which people switch varies between makers and sources, so look at the rated current and duty cycle in your torch manual rather than relying on a rule of thumb.
Do not judge flow by feel. Some makers' manuals say to make sure the coolant is circulating correctly while you weld, and with their own coolers this can be seen as a steady return flow in the cooler's tank. Many coolers also have a flow switch or warning light, so check what yours has.If the return flow stops, the handle gets hot or the cooler alarms, stop welding and find the cause: a low level, a kinked hose, a blocked line or a cooler fault. Running the torch without flow can quickly damage the power cable and the head, so check flow every time you start work.
Look over the cable set before each shift. Insulation on cables and the torch should be undamaged, and defects should be reported rather than worked around. Replace the set if you find cuts, abrasion, kinks, hardened or discoloured sections, bulging or bubbling hose, or weeping at the fittings.A damaged power cable or hose can leak coolant, overheat and, in a worst case, expose live parts, so do not carry on with it or try a temporary repair. Isolate the machine from the mains and switch off the cooler before you disconnect anything, and make sure the replacement is made for the same torch type and cooling method.
Switch off and isolate the machine and the cooler first, and let the torch and coolant cool down, as some coolant stays in the torch body and can be hot after welding.Some torch manuals tell you to seal the coolant hoses with the plastic stoppers supplied whenever they are detached, which stops coolant escaping onto the floor or electrical parts. Keep coolant away from the machine and from live connections, and wipe up spills at once. When you reconnect, match the connectors by their markings or colours, tighten them correctly and check for weeping before you start welding.
