ID=.625 + OD=.750.
Replacement parts for the torch itself - bodies, handles, power cables and backcaps - and how to match them to your torch.
The torch parts are the structural and conducting pieces behind the consumables: the torch body (head), the handle, the power cable, the gas hose where it is a separate item, the backcap and its O-ring, and the heatshield. A torch is normally described as the body plus the cable-hose assembly and other components.The consumables at the front, such as cups, collets and collet bodies, wear faster and are swapped far more often. The torch parts last longer, but they are still wear items: bodies can be damaged by bending or heat, handles crack, cables fray and seals harden. Treat them as a planned replacement, not a lifetime fit.
A flexible body lets you set the head angle to reach awkward joints, which can reduce strain on the hand and wrist. A rigid body is a fixed shape that is simple, steady and suits repeat work where the angle never changes.The trade-off is wear: a flexible neck contains a bendable internal section that can eventually loosen or break if it is bent repeatedly, whereas a rigid body has nothing to flex. Ask what your joints really need. If you rarely change the angle, rigid is usually the more durable choice; if access varies job to job, flexible is more practical. Make sure the body you choose is made for your torch type and current rating.
The backcap screws into the rear of the torch head, holds the tungsten electrode firmly in place and helps keep air from leaking into the head. Backcaps normally come in long, medium and short lengths.Choose by three things: the torch type, because it dictates the size; the access you have to the joint, since short, button-style caps suit tight spaces; and the tungsten length. A long backcap takes a full-length electrode, while medium and short caps are normally used with electrodes cut down to a shorter piece. Keep the right cap for the way you work, and replace one with damaged threads or a loose grip on the electrode.
The O-ring helps seal the rear of the torch head. If it is cracked, flattened, dry or hardened, it may let air be drawn into the shielding gas or let gas escape, which can show up as porous welds or a discoloured tungsten.Inspect the O-ring whenever you remove the backcap to change a tungsten. Replace it if you see cracks, flat spots or brittleness, and always use the right size for your backcap, because one that is too loose leaks and one that is too tight can tear or strain the threads. Some welders add a thin smear of suitable lubricant, but check your manual first. If you still suspect a leak, a soap-solution check at the fittings can help find it.
