    Rapid Ref : 79014400X

    GFX 3.0 Pipe Cutting and Bevelling Machine
    79014400X

    Select Option
    Prices From £3780.00 ex VAT
    Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

    New, innovative saw from Orbitalum Tools for cutting and bevelling of tubes and elbows in just seconds. The perfect preparation for orbital welding! Easy to use, powerful and compact saw with low weight – our new GFX 3.0 provides even more outstanding features:

    • Optimised chip flow due to a new vice design
    • Hardened cast iron clamping jaws
    • Integrated line laser to mark the cut-off point
    • Ergonomically designed motor handle
    • Powerful drive with 1.2 kW and adjustable speed control for cutting several materials and extended tool life
    • Electronic overload protection with integrated temperature monitor and electronic speed regulation
    • Increased durability of tools due to the new drive GF10
    • Ergonomically positioned speed control adjusting wheel
    • Swivel cable with a quick-disconnect coupler for easy and quick replacement of power cables
    • Directly mountable to the workbench

    Product Details

    The machine comes with:

    • 1 Transportation case
    • 1 Saw blade (Code 790 041 035)
    • Toolset set
    • 1 Tube of saw blade lubricant GF TOP (Code 790 060 228)



    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure
       GFX 3.0 Operating Manual
       GFX 3.0 Parts Manual

    Related Items

    GF Pipe Cutting Machines FAQs

    Practical answers on choosing, setting up and using orbital pipe cutting and bevelling machines that carry a small circular saw blade round the pipe.

    Will cutting with an orbital saw machine leave heat marks on stainless steel pipe?icon-minus-redicon-plus-red

    Normally not. These machines use a cold, mechanical cutting process: a small circular saw blade plunges into the pipe and is driven round it, so the pipe is not heated the way it would be by a flame or plasma cutter. That matters on stainless steel, where heat tint and a heat-affected zone can reduce corrosion resistance.

    The cold process only holds if the cut is done properly. A worn blade, the wrong blade for the material, too much feed or a lack of lubricant can still create heat, so use the blade, speed and lubricant recommended in the manufacturer's manual.

    Which materials can this type of machine cut, and do I change the settings for each?icon-minus-redicon-plus-red

    Machines of this type are made to cut and bevel stainless and other high-alloy steels, low-alloy and plain steels, cast materials, non-ferrous metals such as aluminium, copper and brass, and many plastic pipes. Most have an electronic variable speed control so the blade speed can be matched to the material.

    In general, tougher alloys call for a slower blade speed and a blade made for that material, while softer metals and plastics need their own care to avoid clogging or melting. Do not guess: the manual and the blade maker's chart give the speed and blade for each material, and the data plate shows what your machine can handle.

    Why does the wall thickness a machine can cut depend on the material?icon-minus-redicon-plus-red

    Harder, tougher materials need more cutting force and heat the blade more, so a machine that copes with a given wall in mild steel may only manage a thinner wall in a high-alloy steel. For that reason makers usually quote the wall thickness range as depending on the material.

    Makers also note that a thicker wall can sometimes be cut by using a manual feed or by making the cut in more than one pass, depending on the blade diameter. Treat that as something to check, not assume: look up your pipe diameter, wall thickness and material against the machine's application table in the manual before you start.

    How do I mark and line up the cut position accurately?icon-minus-redicon-plus-red

    Many machines include a line laser that projects a line across the pipe to show exactly where the blade will cut. Mark the pipe at the position you want, bring the laser line onto the mark, then clamp the pipe so it cannot slip.

    Allow for the thickness of the blade, and for any material that will be removed by a bevel, when you measure the length you need. Do not look into a laser beam, keep the lens clean, and follow the manual for fitting and aligning the laser, as the method differs between machines.
