RPG 8.6 Accessories FAQs
Questions about tool holders, clamping shells and other accessories for orbital tube squaring and bevelling machines.
What does a tool holder do on a tube squaring and bevelling machine?

The tool holder carries the cutting tool and sets the shape that is machined on the tube end. Different holders are made for different jobs, such as squaring the end flat, or cutting a bevel at a set angle ready for a butt weld. Changing the holder lets one machine prepare ends in more than one way.
Holders are normally made for a particular machine type and size range, so check the data plate and manual for the holders the machine is designed to accept rather than assuming one will fit.
What are clamping shells and why are they used?

Clamping shells are split inserts that fit around the tube and hold it in the machine. Because they match the tube's outside diameter, they spread the clamping force around the tube instead of pinching it at a few points.
That is particularly useful for thin-wall tube, where ordinary jaws can distort the tube. Makers describe shells of this kind as giving deformation-free clamping. A tube that has been squeezed out of round is harder to cut square and harder to fit up for welding.
How do I select the right clamping shells for my tube?

Shells are matched to the tube outside diameter, and for thin-wall tube the wall thickness may also matter, so have the exact outside diameter and wall thickness to hand. Makers normally ask for these when shells are specified.
Each set covers a limited diameter range, and the machine itself has a minimum and maximum tube size, so a set that suits one tube will not necessarily suit the next size. Fit only the shells the manual lists for your machine, and check the tube is gripped firmly but is not marked or distorted.
Can I use the same machine and accessories on stainless steel and carbon steel?

It is best not to, unless the accessories are kept clean and separate. Carbon steel particles picked up from tools or clamping surfaces can embed in stainless steel and later rust, which damages its corrosion resistance. Bevelling and tube machining guidance recommends keeping tools and parts for stainless steel only for that material and storing them apart.
If a shared machine is unavoidable, clean the contact surfaces and fit stainless-only shells and tools, and follow any contamination requirements in your welding specification.
