    Rapid Ref : 79003100X

    Orbitalum RPG 3.0 Tube Squaring Machine
    79003100X

    Select Option
    Prices From £4620.00 ex VAT

    Machine comes included with the following;

    • 1x tube squaring machine
    • 1x durable storage and shipping case
    • 1x WH tool holder
    • 1x MFW multifunctional tool
    • 1x tool set
    • 1x operating instructions and spare parts list

    Brochures & Manuals

    RPG Tube Squaring Machines FAQs

    Tube squaring machines face the ends of thin-walled tube so they are square, burr-free and ready for welding.

    What kind of tube is a tube squaring machine designed for?icon-minus-redicon-plus-red

    These machines are designed for thin-walled tube, mainly stainless steel and other steels, and for small welded fittings, where a clean, square end is needed before orbital welding. The maker states a maximum wall thickness and a range of tube outside diameters for each model, and the clamping shells have to match the diameter you are working on.

    The tool bit is also limited. Makers list the materials their machines are suited to, which typically include alloy and unalloyed steels and some softer metals such as aluminium, and ask you to check with them for anything else. Do not assume a thick-walled pipe can be faced.

    Read the data plate and the manual for the limits of your machine, and choose the model that covers your largest tube.

    What safety precautions should I take when using a tube squaring machine?icon-minus-redicon-plus-red

    The tool spins at the end of the tube, so keep your hands away from it while it runs, tie back long hair and do not wear loose clothing, jewellery or a tie. Wear eye protection against hot, sharp chips. Use the machine only with the tube properly clamped and with the chip shield or viewing window closed, where one is fitted.

    Switch off and let the machine stop completely before you change the tool, change the shells, clean it or remove chips. Pull out the plug or take out the battery first. Safety gloves are for handling sharp chips and cut ends once everything has stopped, and the HSE warns that gloves near rotating machinery raise the risk of entanglement, so keep hands clear of anything that is turning.

    Always follow the maker's manual and your own risk assessment.

    How do I use a mains-powered squaring machine safely?icon-minus-redicon-plus-red

    Before each use, inspect the machine, cable and plug for damage. The HSE advises checking that the cable is not damaged and has not been repaired with tape or an unsuitable connector, and looking for burn marks or discolouration. If anything is damaged, do not use it, and have a competent person repair it.

    Run the machine from a supply protected by a residual current device (RCD). The HSE describes an RCD as a useful safeguard but only a secondary one, and says the user should test it with its test button before use. Keep the cable clear of the cutting area and away from sharp chips, oil and heat, never carry the machine by the cable, and do not leave it running unattended.

    Check that the supply matches the data plate.

    Should I choose a mains or a cordless machine?icon-minus-redicon-plus-red

    Think about where you will use it. A mains-powered machine gives steady power for repeated work in a workshop. A cordless machine suits fitting and site work where there is no convenient socket, but it relies on charged batteries, so plan for a spare charged battery on a bigger job.

    Before using the battery and charger, read the maker's instructions for them completely. Take the battery out before changing tools or cleaning. If the battery runs low the cut can suffer, so charge or swap it.

    Also check that the model covers your largest tube diameter and wall thickness, because the range differs between models.
