    Rapid Ref : 79003800X

    Orbitalum RPG 4.5 Tube Squaring Machine
    79003800X

    Select Option
    Prices From £6195.00 ex VAT

    Designed for burr-free squaring of thin-walled stainless steel tubes. Clean and secure working area with a clear view of the cutting head. Machine with rotating /removable bench stand.

    This machine includes;

    • 1 Durable storage and shipping case
    • 1 WH12-I tool holder
    • 1 Multifunctional tool
    • 1 Toolset
    • 1 Operating manual and spare parts list

    Product Details

    Brochures & Manuals

    Related Items

    • 790038280 Orbitalum WH12-V-45° Standard Tool Holder for Bevelling for RPG 4.5, RPG 8.6, Bevel Angle 45°

      Orbitalum WH12-V-45° Standard Tool Holder for Bevelling for RPG 4.5, RPG 8.6, Bevel Angle 45°

      Rapid ref : 790038280




      £ 206.00 EX VAT


    • 790038282 Orbitalum WH12-V-35° Standard Tool Holder for Bevelling, for RPG 4.5, RPG 8.6, Bevel Angle 35°

      Orbitalum WH12-V-35° Standard Tool Holder for Bevelling, for RPG 4.5, RPG 8.6, Bevel Angle 35°

      Rapid ref : 790038282




      £ 206.00 EX VAT


    • 790038314 Orbitalum Multifunctional Tool MFW-P-2 for RPG Machines

      Orbitalum Multifunctional Tool MFW-P-2 for RPG Machines

      Rapid ref : 790038314




      £ 70.50 EX VAT


    • 790038320 Orbitalum WH15-I Tool Holder for Squaring, for RPG 4.5, RPG 8.6

      Orbitalum WH15-I Tool Holder for Squaring, for RPG 4.5, RPG 8.6

      Rapid ref : 790038320




      £ 198.00 EX VAT


    • 790038326 Orbitalum Tool Holder WH12-U-20° for Bevelling, 20° Bevel Angle, RPG 4.5, RPG 8.6

      Orbitalum Tool Holder WH12-U-20° for Bevelling, 20° Bevel Angle, RPG 4.5, RPG 8.6

      Rapid ref : 790038326




      £ 198.00 EX VAT


    • 7900384XX Orbitalum Stainless Steel Clamping Shell for RPG 4.5, Tube OD 12mm - 114.3mm

      Orbitalum Stainless Steel Clamping Shell for RPG 4.5, Tube OD 12mm - 114.3mm

      Rapid ref : 7900384XX



      From £ 454.00 EX VAT


         Expand Options

    RPG Tube Squaring Machines FAQs

    Tube squaring machines face the ends of thin-walled tube so they are square, burr-free and ready for welding.

    Why square a tube end if the saw cut already looks straight?icon-minus-redicon-plus-red

    A saw or abrasive cut can look straight and still leave a slightly angled face, burrs or scratches. Makers of orbital welding equipment say that high-quality end preparation is required for automatic welding, and that pipe ends should be square, free of burrs and free from contamination, because even small deviations in the joint can lead to weld defects or rework.

    A squaring machine faces the end square to the tube axis in one set-up. Whether you need it depends on your saw cut and on the standard set by your welding procedure or specification, so check those first.

    What safety precautions should I take when using a tube squaring machine?icon-minus-redicon-plus-red

    The tool spins at the end of the tube, so keep your hands away from it while it runs, tie back long hair and do not wear loose clothing, jewellery or a tie. Wear eye protection against hot, sharp chips. Use the machine only with the tube properly clamped and with the chip shield or viewing window closed, where one is fitted.

    Switch off and let the machine stop completely before you change the tool, change the shells, clean it or remove chips. Pull out the plug or take out the battery first. Safety gloves are for handling sharp chips and cut ends once everything has stopped, and the HSE warns that gloves near rotating machinery raise the risk of entanglement, so keep hands clear of anything that is turning.

    Always follow the maker's manual and your own risk assessment.

    How do I use a mains-powered squaring machine safely?icon-minus-redicon-plus-red

    Before each use, inspect the machine, cable and plug for damage. The HSE advises checking that the cable is not damaged and has not been repaired with tape or an unsuitable connector, and looking for burn marks or discolouration. If anything is damaged, do not use it, and have a competent person repair it.

    Run the machine from a supply protected by a residual current device (RCD). The HSE describes an RCD as a useful safeguard but only a secondary one, and says the user should test it with its test button before use. Keep the cable clear of the cutting area and away from sharp chips, oil and heat, never carry the machine by the cable, and do not leave it running unattended.

    Check that the supply matches the data plate.

    Should I choose a mains or a cordless machine?icon-minus-redicon-plus-red

    Think about where you will use it. A mains-powered machine gives steady power for repeated work in a workshop. A cordless machine suits fitting and site work where there is no convenient socket, but it relies on charged batteries, so plan for a spare charged battery on a bigger job.

    Before using the battery and charger, read the maker's instructions for them completely. Take the battery out before changing tools or cleaning. If the battery runs low the cut can suffer, so charge or swap it.

    Also check that the model covers your largest tube diameter and wall thickness, because the range differs between models.
