PATON PROTIG-315-400V WK is an industrial argon-arc welding kit, which is designed for welding thick-walled pieces of a wide range of non-ferrous and ferrous metals: aluminium and its alloys, copper, titanium, stainless steel, cast iron, and all grades of steel with both direct and alternating current up to 315 amperes. It works in TIG AC, TIG DC, TIG MIX, MMA AC/DC, SPOT, Double Pulse, and TIG Lift modes. The machine has a colour LCD screen and can store up to 10 sets of user-configured parameters for each welding mode. The ProTIG-315 benefits from a 50% duty cycle. This machine has a 1-year warranty.
Specification
| Mains Voltage: |
380/400v |
| Welding Current Range: |
10A - 315A |
| Duty Cycle: |
315A at 50%, 200A at 100%
|
| Nominal Power Consumption: |
13.5kVA
|
| Dimensions (L x W x H): |
465mm x 150mm x 350mm
|
| Weight: |
27.7kg
|
| Protection Class: |
IP23 |
Perfect For
- Production companies of the food and chemical industry
- Truck fleets
- Repair shops
- Industrial companies that produce goods using non-ferrous metals and their alloys
