    Rapid Ref : 115810-XL-SET2

    HMT VersaDrive ImpactaDie XL Threader Complete Kit (Metric Fine for Electrical Conduit)
    115810-XL-SET2

    Click here to see what's included

    £559.05  EX VAT
    SSP Suggested Selling Price = £657.70  YOU SAVE £98.65
     Buy in 3 easy interest free payments of £186.35† with

    Create or repair large diameter external threads on metal bar or conduit with VersaDrive ImpactaDie XL kits.

    Offering fast, easy impact-thread cutting in a variety of sizes from M16 - M25 & 5/8" - 1", the ImpactaDie XL system speeds up the challenging and traditionally time-consuming process of creating large external threads.

    • Guide collar ensures straight & true threading
    • Create external threads from M16 - M25
    • Create external threads up to 75mm long
    • Impact chip breaker action for effective swarf evacuation
    • VersaDrive patented shank & modular adapters provide unbeatable jobsite flexibility
    • Use with Impact Wrenches (prevents dangerous kickback)
    • Clean out existing external threads
    • Impact-rated due to dual hardening process - allows up to 15X faster speed than traditional methods

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    HMT ImpactaDie Threader FAQs

    Answers on choosing and using impact-driven die threaders to cut, extend, clean and repair external threads.

    What are metric coarse, metric fine and UNC threads?icon-minus-redicon-plus-red

    These describe the thread system and pitch. For a given diameter the larger pitch is the coarse thread and a smaller pitch is a fine thread, so the same metric diameter can exist in more than one pitch. Metric fine threads are written with the pitch, for example M10 x 1.25, while coarse sizes are normally listed by diameter alone.

    UNC is the coarse inch series and UNF is the fine one; a higher number of threads per inch means a finer thread. Do not assume a nut will fit just because the diameter matches: a coarse nut will not go onto a fine stud. A die is made for one diameter and pitch, so match both and verify the threads per inch or pitch before you start.

    Do I need cutting fluid when threading?icon-minus-redicon-plus-red

    Yes. Cutting fluid reduces friction and heat, helps the die last longer and improves the finish of the thread. Die makers advise applying it to the die before and during cutting, and makers of impact dies say to apply it regularly to limit heat build-up.

    Apply it regularly rather than once, and especially when working on tougher or harder material. Threaded parts can become very hot, so allow them to cool or handle them with care. Wipe off surplus fluid afterwards and check the die and holder for swarf.

    How do I clear swarf and avoid the die jamming?icon-minus-redicon-plus-red

    The usual die-threading technique is to turn forward for a short way, then ease back slightly to break the chip. This also lets fresh lubricant reach the cutting edges. An impact die has a chip-breaking action built into it, but it still pays to check the die and holder or collar periodically and clear any swarf that builds up.

    Keep the tool square to the work and avoid sideways movement or tilting, which can damage the die. Apply firm forward pressure when starting the cut and when reversing off the thread. If the die stalls, back off and clear it instead of forcing it.

    Can I use it to clean up or repair a damaged thread?icon-minus-redicon-plus-red

    Yes, a die is often used on external threads that are rusty, clogged with coating or lightly deformed, to clean up bolts and studs. Use the collar designed for cleaning and rethreading so the die can run the full length of the thread.

    Be aware that a cutting die removes some metal, whereas a thread chaser reforms the existing thread without removing material. Where a thread is badly damaged, worn or missing too much material, replacing the part is usually safer than trying to rescue it. Always match the die to the exact diameter and pitch of the thread.
