    Rapid Ref : 115810-XL-SET3

    HMT VersaDrive STAKIT ImpactaDie XL Complete Kit
    115810-XL-SET3

    Click here to see what's included

    £765.04  EX VAT
    SSP Suggested Selling Price = £900.05  YOU SAVE £135.01
     Buy in 3 easy interest free payments of £255.01† with

    The VersaDrive ImpactaDie XL complete kit is the ultimate solution for creating and repairing large diameter external threads in both Metric Coarse and Metric Fine sizes. Comprising dies and guides in both Metric Coarse M16 - M24 and Metric Fine M16 - M25, this kit offers fast, easy thread cutting for fixings on standard metal bar as well as electrical conduit. Whatever the job and whatever the challenges, the ImpactaDie XL complete kit will ensure you have the tools needed to quickly and easily tackle the issue whether it be unexpected last-minute modifications, every-day workshop use or emergency on-site repairs. The VersaDrive ImpactaDie XL system can be used with high torque impact wrenches and high-power magnetic drills. The complete kit also includes the unique VersaDrive ImpactaBurr chamfer tool which can be used to prepare a new bar ready for threading and comes supplied in a VersaDrive STAKIT compatible ETOP2 half top case.

    • Guide collar ensures straight & true threading
    • Create external threads from M16 - M25
    • Create external threads up to 75mm long
    • Impact chipbreaker action for effective swarf evacuation
    • VersaDrive patented shank & modular adapters provide unbeatable jobsite flexibility
    • Use with Impact Wrenches (prevents dangerous kickback)
    • Clean out existing external threads
    • Impact-rated due to dual hardening process - allows up to 15X faster speed than traditional methods
    • Contents includes; ImpactaDie XL holder, Guide Collar, Flush Collar, M16 / M20 / M24 Metric Coarse Hex Die Nuts, M16 / M20 / M25 Metric Fine Hex Die Nuts, M16 / M20 / M24 / M25 Guides & ImpactaBurr 36mm Chamfer Tool.

    HMT ImpactaDie Threader FAQs

    Answers on choosing and using impact-driven die threaders to cut, extend, clean and repair external threads.

    How do I work out the thread size and pitch I need?icon-minus-redicon-plus-red

    You need two values: the outside (major) diameter and the pitch. Measure the diameter across the crests of the thread with calipers, then try the leaves of a thread pitch gauge until one sits fully along the thread, and read the number stamped on it.

    Metric threads are stated as diameter by pitch in millimetres, for example M8 x 1.25. Inch threads are stated as threads per inch. Compare your result against a thread table, and check that a matching nut runs on smoothly by hand. If the nut does not turn freely, stop and re-check instead of forcing it, because that can damage both parts.

    Do I need to chamfer the end of the bar first?icon-minus-redicon-plus-red

    Yes, it helps. Die-threading guidance says to chamfer or bevel the end of the rod or bar before cutting, so the die can start square and grip properly.

    Some kits include a chamfering tool for this. Without a chamfer, the die may start badly, bind or cut a rough first thread. Remove any burr left from cutting the bar, and check that the end is clean and square before starting. Follow the instructions supplied with your kit for the size of chamfer.

    How do I clear swarf and avoid the die jamming?icon-minus-redicon-plus-red

    The usual die-threading technique is to turn forward for a short way, then ease back slightly to break the chip. This also lets fresh lubricant reach the cutting edges. An impact die has a chip-breaking action built into it, but it still pays to check the die and holder or collar periodically and clear any swarf that builds up.

    Keep the tool square to the work and avoid sideways movement or tilting, which can damage the die. Apply firm forward pressure when starting the cut and when reversing off the thread. If the die stalls, back off and clear it instead of forcing it.

    Can I use it to clean up or repair a damaged thread?icon-minus-redicon-plus-red

    Yes, a die is often used on external threads that are rusty, clogged with coating or lightly deformed, to clean up bolts and studs. Use the collar designed for cleaning and rethreading so the die can run the full length of the thread.

    Be aware that a cutting die removes some metal, whereas a thread chaser reforms the existing thread without removing material. Where a thread is badly damaged, worn or missing too much material, replacing the part is usually safer than trying to rescue it. Always match the die to the exact diameter and pitch of the thread.
