    Rapid Ref : 302820

    HMT VersaDrive ImpactaDie 24mm Hex Die Nut - UNC Sizes
    302820

    Select Option
    Prices From £28.09 ex VAT

    HMT ImpactaDie Threader FAQs

    Answers on choosing and using impact-driven die threaders to cut, extend, clean and repair external threads.

    How do I work out the thread size and pitch I need?icon-minus-redicon-plus-red

    You need two values: the outside (major) diameter and the pitch. Measure the diameter across the crests of the thread with calipers, then try the leaves of a thread pitch gauge until one sits fully along the thread, and read the number stamped on it.

    Metric threads are stated as diameter by pitch in millimetres, for example M8 x 1.25. Inch threads are stated as threads per inch. Compare your result against a thread table, and check that a matching nut runs on smoothly by hand. If the nut does not turn freely, stop and re-check instead of forcing it, because that can damage both parts.

    Do I need to chamfer the end of the bar first?icon-minus-redicon-plus-red

    Yes, it helps. Die-threading guidance says to chamfer or bevel the end of the rod or bar before cutting, so the die can start square and grip properly.

    Some kits include a chamfering tool for this. Without a chamfer, the die may start badly, bind or cut a rough first thread. Remove any burr left from cutting the bar, and check that the end is clean and square before starting. Follow the instructions supplied with your kit for the size of chamfer.

    How do I clear swarf and avoid the die jamming?icon-minus-redicon-plus-red

    The usual die-threading technique is to turn forward for a short way, then ease back slightly to break the chip. This also lets fresh lubricant reach the cutting edges. An impact die has a chip-breaking action built into it, but it still pays to check the die and holder or collar periodically and clear any swarf that builds up.

    Keep the tool square to the work and avoid sideways movement or tilting, which can damage the die. Apply firm forward pressure when starting the cut and when reversing off the thread. If the die stalls, back off and clear it instead of forcing it.

    Can I use it to clean up or repair a damaged thread?icon-minus-redicon-plus-red

    Yes, a die is often used on external threads that are rusty, clogged with coating or lightly deformed, to clean up bolts and studs. Use the collar designed for cleaning and rethreading so the die can run the full length of the thread.

    Be aware that a cutting die removes some metal, whereas a thread chaser reforms the existing thread without removing material. Where a thread is badly damaged, worn or missing too much material, replacing the part is usually safer than trying to rescue it. Always match the die to the exact diameter and pitch of the thread.
