Rapid Ref : 850250

HMT Steelbor S50 Dual-Speed Magnet Drill Kit
850250

Select Option
Prices From £728.00 ex VAT

The S50 combines compact power with 2-speed control — ideal for heavy drilling and versatile site work up to 55mm. Positioned between ultra-compact and high torque models, the S50 delivers reliable, all-day performance for broaching, reaming and countersinking. With a 160mm stroke, it accepts long cutters and integrates seamlessly with both VersaDrive & Weldon tooling systems.

  • 2-speed motor for cutting control and material flexibility
  • Drills up to 55mm diameter with TCT cutter performance
  • 160mm stroke supports long broach cutters & reamers
  • Protective case and accessories supplied as standard
  • VersaDrive adapter available for modular system use
  • Ideal for structural and fabrication shop environments

Product Details

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure

HMT Mag Drills FAQs

Straight answers to the questions people ask most when choosing and using magnetic drilling machines.

What is a magnetic drill and what is it used for?icon-minus-redicon-plus-red

A magnetic drill is a portable drilling machine with a powerful electromagnet in its base. When switched on, the magnet clamps the machine firmly to steel, so you can drill accurate holes on site or in the workshop without a drill press.

It is mainly used with annular (hollow core) cutters to make clean holes in structural steel, plate, beams, channel, pipe and fabrications. It is widely used in steel erection, fabrication, shipbuilding, rail and plant maintenance.

Corded or cordless magnetic drill - which is better?icon-minus-redicon-plus-red

It depends on where you work. A corded machine gives consistent power for long runs of production drilling and heavy cutters. A cordless machine is far more convenient on site, at height or where no supply is close, and avoids trailing leads.

Cordless models rely on battery capacity, so plan the number of holes per charge and keep a spare battery for a full day's work. For the largest holes and continuous drilling, many users still prefer mains power. Check the manufacturer's stated hole capacity for each type.

What can a magnetic drill be fixed to, and what affects the magnet's grip?icon-minus-redicon-plus-red

The magnet only holds well on ferrous steel. It will not grip aluminium, stainless steels that are non-magnetic, copper or plastics, so those need a clamp, vacuum base or other fixing method.

Holding force depends on the thickness, flatness and cleanliness of the steel. Thin sheet, rough or painted surfaces, rust, swarf under the base and curved surfaces all reduce the grip. Clean the surface and the magnet face, and use the manufacturer's guidance on minimum material thickness. On pipe or uneven work, use a suitable pipe or V-base and a safety chain or strap.

What speed and feed should I use?icon-minus-redicon-plus-red

Larger cutters need slower speeds and smaller cutters faster ones, and harder or tougher materials such as stainless steel need slower speeds than mild steel. A variable speed machine lets you match the speed to the cutter and the job.

Feed steadily with even pressure and let the cutter do the work. Forcing it overloads the motor and chips the teeth; too light a feed makes it rub and blunt. The cutter manufacturer's speed recommendations should be your starting point. Listen for the sound: a steady cut and a continuous swarf curl suggest you are close.
