Rapid Ref : K14439-1

Lincoln Sprinter 180T DC TIG Inverter Welder Power Source - 110/230v
K14439-1

£555.00  EX VAT
SSP Suggested Selling Price = £693.53  YOU SAVE £138.53
 Buy in 3 easy interest free payments of £185.00 with
Lincoln’s Sprinter T range offers power in a small package. Weighing in under 9kg, the Sprinter T is lightweight and portable, and the 180/200-amp output enables you to weld electrodes up to 4.0 mm, including 7018 and 6010. This machine combines superior stick capabilities with high-frequency TIG, pulsed TIG mode and dual input voltage (120V/230V). A simple display allows the operator to dial the weld settings so you can get started quickly and easily on any job anywhere – maintenance work, light-fabrication, light structural and everything in between. The Sprinter T is a TIG and STICK welder and so much more.

  • DUAL INPUT VOLTAGE – 120V and 230V, enabling you to plug into any common power supply.
  • PULSED TIG MODE – Provides heat management and enhanced control when making thin, precise welds.
  • HIGH FREQUENCY START – Strike a precise arc every time while TIG welding
  • HOT START – This is a temporary increase in the initial welding current, to help ignite the arc quickly and reliably.
  • ARC FORCE – helps to increase penetration and prevent electrodes from sticking.
  • MULTI-PROCESS CAPABLE – Welds DC stick, DC Lift TIG and DC TIG HF mode
  • LIGHTWEIGHT PORTABILITY – weighing under 9 kg, this durable machine is easy to carry with either the ergonomic handle or shoulder strap.
  • TWO STICK MODES – Dedicated E6010 and E7018 weld modes allow for greater welding versatility and superior performance.
  • PFC – Resistant to power fluctuations, even while working on long extension cables up to 100m, without affecting welding capability and quality.

Product Details

Specification

Input power  120/230v 1ph/50 Hz +/- 15%
Rated output current/duty cycle (230Vac - GTAW) 180A @ 45%
Output range (230Vac) - TIG  10-180A DC
Output range (230Vac) - MMA 20-160A DC
Fuse size (A) 16
Open circuit voltage (OCV) Average OCV - 69V
Peak OCV - 95V
VRD OCV (Peak) - 14V
Dimensions HxWxD (mm) 162 x 305 x 438
Protection / insulation class IP23S/H
Net weight (kg) 9
