    Rapid Ref : Thermal14pin-LA-RC

    CK Amptrak Linear Amperage Control with Velcro Straps for Thermal Dynamics Machines, 14 Pin Plug.
    Thermal14pin-LA-RC

    Select Option
    Prices From £236.67 ex VAT

    The Amptrak™ remote current control provides remote on-off control of the welding machine contactor and/or gas and water solenoid control, as well as a full range current output control. The fitted Velcro straps are a one size fits all solution that can be easily retrofitted to all torch handle diameters. A built in strain-relief prevents the control cord from being pulled out or damaged.

    • Linear slide actuator for complete on/off and full amperage control
    • Velcro strap attachment to fit all TIG torches
    • Adapts to most standard TIG power supplies
    • Protected against high frequency

    Compatible with Thermal Dynamics Machines, 5K Ohm Potentiometer rating, 8 Pin Plug.

    Product Details


    Thermal Arc Machine Remotes FAQs

    Hand-mounted amperage controls and foot pedals for TIG machines: how they work, how to choose between them and how to keep them in good order.

    What is a hand-mounted amperage control and how does it attach to the torch?icon-minus-redicon-plus-red

    It is a small control that fastens to the torch handle so you can change the welding current with a finger or thumb while you weld. Some are a slide moved like a trigger, others a wheel, and many also include a switch to start and stop the arc.

    Many fasten with hook-and-loop straps, so they suit a range of handle sizes and can be moved or removed without tools. Check that the control suits your torch handle, and that its plug and wiring suit your machine. The data plate and manual of the machine tell you what type of remote it accepts.

    Will a hand-mounted control or pedal let me exceed the current set on the machine?icon-minus-redicon-plus-red

    No. On most machines the panel current is the maximum, and the remote adjusts the output from the machine's minimum up to that set value. Turning the control to full gives you the panel setting, not more.

    So set the panel to the highest current you expect to need for the job, then use the control to reduce it as required. Some machines sense that a remote is plugged in and switch automatically, while others need remote mode selecting by hand. If the machine does not switch over, you can get full panel current at the start of the weld, which can burn through thin material.

    How do I look after the cable and plug on a hand-mounted control or pedal?icon-minus-redicon-plus-red

    Check them before use. HSE advice for portable electrical equipment is to look for damage to the cable or plug, a cable not held firmly where it enters the plug, and damaged casing. If you find any, take it out of use and have it repaired or replaced by a competent person.

    Beyond that, keep the cable clear of hot metal and spatter, do not pull on it to unplug, and store the control where it will not be crushed. Hook-and-loop straps wear and collect debris, so replace them when they stop gripping.

    Do I need to worry about ozone when TIG welding stainless steel or aluminium?icon-minus-redicon-plus-red

    It is worth knowing about. HSE says ozone can be produced when TIG welding stainless steel and aluminium, and that it can cause throat dryness, coughing or chest tightness. Extreme exposure can cause fluid on the lungs.

    HSE guidance is that indoor welding fume should be controlled with engineering controls such as local exhaust ventilation, with respiratory protective equipment as well where that alone is not enough. Even for occasional welding, HSE says respiratory protective equipment and good general ventilation should be provided. A particulate filter alone does not protect against welding gases. Follow your risk assessment and the manufacturer's instructions for your equipment.
