    Rapid Ref : CK-225AHSF - BSP  Mfr Ref : 225AHSF

    CK 7.6m (25ft) Superflex Argon Hose, G3/8" Machine Connection 45V10SF
    225AHSF CK-225AHSF - BSP

    £54.91  EX VAT
    SSP Suggested Selling Price = £83.60  YOU SAVE £28.69
     Buy in 3 easy interest free payments of £18.30† with

    CK MR140 Torch Parts FAQs

    Spare parts for a water-cooled micro TIG torch: what wears, what each part does and how to match the right replacement.

    Which parts of a micro torch wear out and how can I tell?icon-minus-redicon-plus-red

    Typical wear items are the tungsten, collet, collet body or gas lens, cup, O-rings, insulator and back cap. Look for a tungsten that will not stay gripped, a collet or body with damaged threads or heat marks, a cracked or chipped cup, and a seal that is flattened or missing. Too much current can overheat and distort the collet and collet body.

    Torch makers advise checking all the consumable parts before each use, cleaning them and replacing any that are damaged straight away. Wear depends on the current, the duty cycle and how carefully the torch is handled, so there is no fixed replacement interval.

    What should I check on the power cable, gas hose and water hoses?icon-minus-redicon-plus-red

    Switch off the power source, disconnect it from the mains and shut off the gas and coolant before handling the cable assembly. Then check the cable and its insulation, the gas hose, the water hoses and all connectors for cuts, kinks, heat damage or looseness, and keep the contact surfaces clean so they make good electrical contact. Check the insulation on the handle and other insulated parts too.

    Torch makers say to replace damaged parts rather than make temporary repairs. Do not use a torch with a damaged cable or connector, and have any repair to the cable assembly done by a competent person following the maker's manual.

    How can I tell if a water-cooled torch has a leak, and what do I do?icon-minus-redicon-plus-red

    Signs include drips or damp at the torch head, handle or hose joints, a falling coolant level, or a torch that overheats. The leak may start somewhere other than where the water shows, such as the cooler, a water line, the cable or the neck. Common causes are loose connections, worn seals or O-rings and a damaged hose. Low coolant flow can overheat the torch, and a liquid-cooled cable assembly can leak if it overheats.

    Stop welding and switch off. Touching live metal parts can give a fatal electric shock, so never carry on welding with a leak. Replace the faulty part with the correct one, use the coolant the maker specifies, and check the level and the flow before striking an arc.

    What should I know about thoriated electrodes when buying spare tungsten?icon-minus-redicon-plus-red

    Thoriated tungsten contains a small amount of radioactive thorium. The greatest hazard is the fine dust made when grinding, not the welding itself, so grinding should be done on a dedicated wheel with local dust extraction, with suitable respiratory protection worn unless only a very small number of electrodes is ground, and eye protection if the wheel has no viewing screen. Ceriated or lanthanated electrodes are generally acceptable alternatives, and using a thoriated type should be justified.

    HSE guidance on welding fume points to local exhaust ventilation for regular TIG welding indoors. When you buy spare tungsten, check the type marking on the pack and the safety data sheet, and consider in your risk assessment whether a thorium-free type would do the job.
