    Rapid Ref : 115810-XL-SET1

    HMT VersaDrive ImpactaDie XL Threader Complete Kit (Metric Coarse)
    115810-XL-SET1

    Click here to see what's included

    £556.07  EX VAT
    SSP Suggested Selling Price = £654.20  YOU SAVE £98.13
     Buy in 3 easy interest free payments of £185.36† with

    Create or repair large diameter external threads on metal bar or conduit with VersaDrive ImpactaDie XL kits.

    Offering fast, easy impact-thread cutting in a variety of sizes from M16 - M25 & 5/8" - 1", the ImpactaDie XL system speeds up the challenging and traditionally time-consuming process of creating large external threads.

    • Guide collar ensures straight & true threading
    • Create external threads from M16 - M25
    • Create external threads up to 75mm long
    • Impact chip breaker action for effective swarf evacuation
    • VersaDrive patented shank & modular adapters provide unbeatable jobsite flexibility
    • Use with Impact Wrenches (prevents dangerous kickback)
    • Clean out existing external threads
    • Impact-rated due to dual hardening process - allows up to 15X faster speed than traditional methods

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure

    HMT ImpactaDie Threader FAQs

    Answers on choosing and using impact-driven die threaders to cut, extend, clean and repair external threads.

    How do I work out the thread size and pitch I need?icon-minus-redicon-plus-red

    You need two values: the outside (major) diameter and the pitch. Measure the diameter across the crests of the thread with calipers, then try the leaves of a thread pitch gauge until one sits fully along the thread, and read the number stamped on it.

    Metric threads are stated as diameter by pitch in millimetres, for example M8 x 1.25. Inch threads are stated as threads per inch. Compare your result against a thread table, and check that a matching nut runs on smoothly by hand. If the nut does not turn freely, stop and re-check instead of forcing it, because that can damage both parts.

    What are metric coarse, metric fine and UNC threads?icon-minus-redicon-plus-red

    These describe the thread system and pitch. For a given diameter the larger pitch is the coarse thread and a smaller pitch is a fine thread, so the same metric diameter can exist in more than one pitch. Metric fine threads are written with the pitch, for example M10 x 1.25, while coarse sizes are normally listed by diameter alone.

    UNC is the coarse inch series and UNF is the fine one; a higher number of threads per inch means a finer thread. Do not assume a nut will fit just because the diameter matches: a coarse nut will not go onto a fine stud. A die is made for one diameter and pitch, so match both and verify the threads per inch or pitch before you start.

    Do I need to chamfer the end of the bar first?icon-minus-redicon-plus-red

    Yes, it helps. Die-threading guidance says to chamfer or bevel the end of the rod or bar before cutting, so the die can start square and grip properly.

    Some kits include a chamfering tool for this. Without a chamfer, the die may start badly, bind or cut a rough first thread. Remove any burr left from cutting the bar, and check that the end is clean and square before starting. Follow the instructions supplied with your kit for the size of chamfer.

    Do I need cutting fluid when threading?icon-minus-redicon-plus-red

    Yes. Cutting fluid reduces friction and heat, helps the die last longer and improves the finish of the thread. Die makers advise applying it to the die before and during cutting, and makers of impact dies say to apply it regularly to limit heat build-up.

    Apply it regularly rather than once, and especially when working on tougher or harder material. Threaded parts can become very hot, so allow them to cool or handle them with care. Wipe off surplus fluid afterwards and check the die and holder for swarf.
