    Rapid Ref : 601026-0030

    HMT GoldMax 82° Magnet Drill Countersink 2" - Weldon Shank
    601026-0030

    £143.91  EX VAT
    SSP Suggested Selling Price = £169.30  YOU SAVE £25.39
     Buy in 3 easy interest free payments of £47.97† with

    HSS-XE Countersinks now benefit from the special GoldMax coating for increased tool life, even without a lubricant. Standard 19.05mm Weldon shank for use in all standard magnet drills.

    GoldMax coating keeps countersinks sharp much longer than standard HSS tools. Save money with longer-life tooling.

    Product Details

    HMT Countersinks FAQs

    Answers to common questions about choosing and using countersinks for magnetic drills, drill presses and power drills.

    Should I choose an 82 degree or a 90 degree countersink?icon-minus-redicon-plus-red

    Match the countersink angle to the screw head. Metric countersunk screws, including metric flat head socket screws, normally have a 90 degree head. Inch (UNC/UNF) flat head screws normally have an 82 degree head.

    The two are not interchangeable. A 90 degree head in an 82 degree recess sits deeper and leaves a gap around the edge. An inch head in a 90 degree recess tends to stand proud of the surface. Check the screw standard or the head drawing if you are unsure, and cut a test piece before you start on the real work.

    How large should the countersink diameter be for a given screw?icon-minus-redicon-plus-red

    The countersunk diameter at the surface should be slightly larger than the maximum diameter of the screw head, so the head can seat fully and finish flush. The allowance needed is small, so use the screw maker's head dimensions or a fastener table rather than guessing.

    The clearance hole must already be the right size for the screw shank, and the countersink cutter must be big enough to cut the full recess diameter. For a pattern of holes, trial one on an offcut of the same material and thickness, then check the screw sits as intended before committing to the job.

    How do I get the screw heads to sit flush and not stand proud or sink too far?icon-minus-redicon-plus-red

    Depth controls how far the head sits. Too shallow and the head stands proud; too deep and it sinks below the surface and loses bearing area. Cut a little at a time and test-fit a screw, rather than cutting to full depth in one go.

    A depth stop, or a fixed depth setting on the machine, helps keep every hole in a pattern the same. Because material hardness and thickness vary, trial the setting on a scrap piece first, and re-check the first holes of each batch.

    What is the difference between a countersink and a counterbore?icon-minus-redicon-plus-red

    A countersink cuts a cone-shaped recess that matches a countersunk (flat head) screw, so the head sits flush. A counterbore cuts a cylindrical recess with a flat bottom, which is what a socket head cap screw or a bolt head with a washer needs.

    Countersinks are also used to chamfer or deburr the edge of a drilled or tapped hole, which gives a lead-in for a tap or screw and removes sharp edges. If you only need to break an edge, a countersink is the usual tool; if the fastener has a flat-underside head that must be recessed, you need a counterbore.
