100 Series Parts FAQs
Spare protection plates, filters, headbands, sweatbands, magnifying lenses and neck and ear covers for an auto-darkening welding helmet, and how to choose the right ones.
How do I work out which spare parts fit my helmet?

Start with the helmet itself. Look for the model marking on the shell, the filter and the headgear, and check the user manual, which normally lists the compatible spares. If you still have the old part, note any part number printed or moulded on it and measure its width and height.
The HSE says PPE should be maintained using the correct replacement parts and following the manufacturer's replacement schedule. Plates, filters and headgear from one helmet series often do not fit another, even when they look alike, so do not rely on a 'looks the same' match. Our team can help you match a part if you send the details from the helmet.
What is the difference between an inside and an outside protection plate?

Both are clear, replaceable plates that protect the auto-darkening filter. The outside plate sits in front of the filter and takes the spatter, scratches and grinding dust. The inside plate sits between the filter and your face and protects the filter's inner surface from dust, sweat and scratches.
Makers' manuals say the filter must only be used with the inside plate fitted, and that a damaged or pitted outside plate should be replaced, so do not weld with either plate missing. Plates are made for a particular helmet or filter size, so check the fit before ordering. A plate is a consumable part, so it is normal to replace it several times during the life of the filter.
When should I replace a protection plate?

There is no single interval that suits everyone, because it depends on the process, the amount of spatter and how often you weld. Inspect the plates before each shift. Replace an outside plate once it is pitted, scratched, cracked, hazy or too dirty to clean with a soft cloth, and replace an inside plate when it is damaged or when spatter stops you seeing clearly.
A marked outer plate can also block light from the filter sensors and make an auto-darkening filter behave oddly. Replacing a plate early is better than damaging the filter behind it. Always follow the helmet manual.
How do I choose the power of a magnifying lens?

A magnifying lens, sometimes called a cheater lens, sits behind the filter and makes close detail easier to see. Strength is given in diopters, and the higher the number, the closer you need to hold the work. A rough method is to find the reading-glasses strength that gives a sharp view at your usual working distance and use that as a starting point.
Fine work such as TIG often suits a stronger lens than rough work done at arm's length. Try a lens in your normal position before ordering several, and make sure it is sized for your helmet's filter holder. If you wear prescription glasses, ask your optician for advice.
