    Rapid Ref : 0323-0324

    GCE Type 55 Size 10 Heating Nozzle 11"
    0323-0324

    £108.14  EX VAT
    SSP Suggested Selling Price = £135.18  YOU SAVE £27.04
     Buy in 3 easy interest free payments of £36.05† with

    Victor type 55 High Capacity propane heating nozzle for heat treating, straightening and priming.

    Size: 10
    Gas: Acetylene
    Min Flow: 4200 LPH
    Max Flow: 5600 LPH
    BTU Rate: 2498
    Min Total BTU: 374,700
    Max Total BTU: 499,600

    ESAB GCE Gas Torch Parts FAQs

    Replacement nozzles, heating tips, mixers and elbows for oxy-fuel torches: how to identify the right part and keep the torch working safely.

    Can I use the same nozzle with acetylene and with propane?icon-minus-redicon-plus-red

    Not safely as a rule. Each torch should be fitted with the nozzle for its fuel gas, so a nozzle made for one fuel is generally not the right design for another. Propane burns differently from acetylene, and nozzles for the two are usually built differently.

    If you want to change fuel, you generally need the torch and nozzle designed for it, and you must check that the hoses, regulators and flashback protection are suitable for that gas as well. Check the torch maker's documentation first, and never modify nozzles or fittings to make them fit.

    What is a heating tip used for?icon-minus-redicon-plus-red

    Oxy-fuel equipment is used for welding, cutting, heating and straightening. A heating tip is a nozzle designed to give broad heat rather than a cutting jet, so it is used for jobs such as preheating, bending, freeing seized parts and straightening.

    Multi-flame or rosebud-style heads spread heat over a wider area, while single-flame tips give a more concentrated flame. The right tip depends on the fuel gas, the size of the job and your torch, so use the maker's chart. Heating tips do not replace cutting nozzles, and never use a heating tip to cut.

    Why does my torch backfire, and what should I check?icon-minus-redicon-plus-red

    A backfire is the flame burning back into the torch, often with a sharp bang. It may happen when the torch is held too close to the workpiece, or when the nozzle is partly blocked. Backfires do not usually cause injury or damage, but can indicate a fault in the equipment.

    If one occurs, shut the torch valves (oxygen first, then fuel), close both cylinder valves, cool the torch if necessary and then inspect the equipment, especially the nozzle. Do not relight until you have found the cause. A damaged, blocked or badly seated nozzle should be cleaned or replaced.

    How do I test the torch and nozzle connections for leaks?icon-minus-redicon-plus-red

    Use a proprietary leak detecting spray or solution made for oxy/fuel systems, and do not use soapy water or any solution containing grease or oil on oxygen systems. Never look for a gas leak with a naked flame.

    Repair or replace any leaking component immediately. Check the nozzle nut and seating, the torch valves and every hose connection, and do this regularly. Equipment used in tough conditions normally needs more frequent checks. If a leak will not stop after tightening a fitting properly, take that equipment out of use and have it repaired or replaced.
